UV Printer for Canvas Holdall Which Roll to Roll or Sheet to Sheet

UV Printer for Canvas Holdall Which Roll to Roll or Sheet to Sheet thumbnail-1
UV Printer for Canvas Holdall Which Roll to Roll or Sheet to Sheet photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Other, digital printer
Place of Origin:
Guangdong, China
Contact Supplier Request Quote Chat Now
Guangzhou Yinghe Electronic Instruments Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Other, digital printer
Place of Origin Guangdong, China
Brand Name yinghe
Model Number YH330KX
Usage Bill Printer, Card Printer, Cloths Printer, Label Printer, Paper Printer, Tube Printer
Automatic Grade Automatic
Voltage 220V
Dimensions(L*W*H) 503x100x173CM
Weight 900KG
Certification ce
After-sales Service Provided Engineers available to service machinery overseas

Feature

1. LED-UV roll to roll printer with KM 1024 14PL printhead, high printing speed and high resolution

2. 4 colors, 6 colors, white, top coating optional.

3. Maximum printheads quantity can be 8pcs

4. The fastest printing speed is 80sqm/hr.



Parameer

Model YH-3304KX YH-3306KX YH-3308KX
Printhead KM 1024 14PL
Number of Printhead 4 6 8
Maximum Print Width 3.2M(126inch)
Resolution 1440dpi
Color CMYK  CMYK Lc Lm  CMYK
Print Speed High 40 sqm/hr 40 sqm/hr 80 sqm/hr
Standard 30 sqm/hr 30 sqm/hr 60 sqm/hr
Ultra 20 sqm/hr 20 sqm/hr 40 sqm/hr
Media Paper, Advertising Banner, PVC, Mesh Fabrics, Vinyl,Light Boards
Maximum Print quality 1440DPI
Auto Media System Equipped
Image Format Bitmap, TIFF, Quark Xpress, JPGEG, AI, EPS, PDF
Auto Cleaning System Positive Pressure Cleaning
Spray in Idel Function
Color Management Superior ICC Profile
Work Flow RIP and Print at the same time/Print after RIP
Print Interface USB 2.0
Ink Type LED-UV Curing Ink
Software Photoprint 10 software
Work Station Microsoft Windows 2000 or Windows XP
Operating Environment 220V~( 10%)>15A,50Hz/60Hz
Machine Dimension 503x100x173CM
Wooden Case Dimension 550x110x176CM



Warranty policy:
1.  one year guarantee.
2.  12 months the main parts replace for free (except printhead)
3.  All lifetime detailed technical services( include online training and technology solution)
