Help CenterYX 1400 4X8 Automatic & Semi-automaic Lamination Line
Related Products
Specifications
YX 1200 with auto feeding, cleaning, vacuum unloading and trimming etc. 1200pcs board per day. Using japanese or germany parts.
The main technical parameter of 1400T 4×8 hot press machine semi-automatic line
1, Total pressure: P=14000KN
2, Size of heating plate: 2600mm×1400(mm)
3, The size of board:2460×1250(mm)
4, Main cylinder:Dia=340mm Quantity:6
5, Daylight : H=270mm
6, Loading in width direction, Paper feed manually, automatic trimming
1) Pallet Lifter
When the fork clip load the pallet board into the lifter , it star to push board one by one. It was control by photoelectricity switch.
2) Pusher & conveyor
Belt conveyor transfer the board into cleaner.
3) Cleaner
By using brush and vacuum to cleaning the dust of the board surface.
4) Board Transfer System
It will pick up the clean board on the top of paper
5) Paper Stock Frame
Stock the roll paper
6) Belt Feeding Table
Belt feeding table will feed the board with paper automatically. The belt design for high temperature as well.
7) Main Press
By using additional thicker parts to promote the strength of body. Extend the lift time.
8) Vacuum Unloading System
Easy way to unload the finished products, less damage as well. It was brand air cylinder.
9) Conveyor for trimming and checking
When the board passing this position, it will auto trimming the left and right side. Then the trimming system will trim the rest two sides. After finish it, the cylinder will pick up the board and to check the bottom side of finished products.
10) Stock lifter with two position(option)
We supply two position of stock pallet A&B
