Help CenterH13 Hot Work Die Steel Plate (DIN 1.2344 / JIS SKD61)
Related Products
-
Hot Work Tool Steel AISI H13 / DIN 1.2344US$ 2,100 - 3,200MOQ: 20 Tons -
4Cr5MoSiV1(H13,1.2344,8407,SKD61) Hot Work Steel Mould Steel Round BarNegotiableMOQ: 20 Tons
-
H13 Tool SteelUS$ 2,100 - 2,300MOQ: 20 Tons
-
SAE1045 S45C Carbon Steel Round BarNegotiableMOQ: 20 Tons
-
Mould Making Steel Plate P20+Ni\718\1.2738NegotiableMOQ: 20 Tons
Specifications
1.Hot Work Die Steel H132.Hot rolled or forging
3.Black or Machined surface
4.EAF or ESR material
5.Superior Quality
Hot Work Die Steel AISI H13
1, Steel Grade:
AISI H13, JIS SKD61, DIN 1.2344, ASSAB 8407 Mould Steel
2, Flat Bar Size: 20-300 in thickness, 205-2200 in width, 2000-5800 in length
3, Round Bar Size: Dia 60-300mm
4, Chemical Composition
Element |
C |
Si |
Mn |
Cr |
Mo |
V |
P |
S |
content |
0.32~0.45 |
0.80~1.20 |
0.20~0.50 |
4.75~5.50 |
1.10~1.75 |
0.8~1.2 |
≤0.030 |
≤0.030 |
5, Feature
It is a kind of air hardened hot work mould steel
1) widely used, high purity
2) high hot strength and hardness.
3) good tenacity, thermal fatigue ability and abrasion resistance under medium temperature.
4) low heat treatment deformation and small trend to produce scale under air quenching,having resistance to attack of molten metal aluminum.
6, Applications (1.2344 mould steel)
Widely used in aluminum alloy casting mould and extruding mold, die casting, forging die and thermal cutting blade etc.
