CPU Atom N270 SLB73 Intel Processor 512K Cache, 1.60 GHz, 533 MHz cpu processor Quality Choice Most Popular

Specifications

cpu processor SLB73
new on hand
low price and good price
batch order disscount
accept paypal T/T western union



CPU  Atom N270 SLB73 AU80586GE025D Intel Processor N270(512K Cache, 1.60 GHz, 533 MHz FSB)    cpu processor SLB73













Product Overview

The Intel Atom processor N270,Δ implemented in 45nm technology, is power-optimized and delivers robust performance-per-watt for cost-effective embedded solutions. Featuring extended lifecycle support, this processor offers an excellent solution for embedded market segments such as digital signage, interactive clients (kiosks, point-of-sale terminals), thin clients, digital security, residential gateways, print imaging, and commercial and industrial control. The processor remains software compatible with previous 32-bit Intel architecture

and complementary silicon. This single-core processor is validated with the Mobile Intel

945GSE Express chipset, consisting of the Intel 82945GSE Graphics Memory Controller Hub and Intel I/O Controller Hub 7-M. The chipset features power-efficient graphics with an

integrated 32-bit 3D graphics engine based on Intel Graphics Media Accelerator 950 architecture with SDVO, LVDS, CRT, and TV-Out display ports. It provides rich I/O capabilities and flexibility via high-bandwidth interfaces such as PCI Express,* PCI, Serial ATA, and Hi-Speed USB 2.0 connectivity. It also includes a single channel for 400/533 MHz DDR2 system memory (SODIMM or memory down), and Intel High Definition Audio1 interface.

Product Highlights

• Intel Atom processor N270 at 1.6 GHz core speed with 533 MHz AGTL+ front-side bus (FSB) and 2.5 watts thermal design power2 (TDP)

• Intel’s hafnium-based 45nm Hi-k metal gate silicon process technology reduces power consumption, increases switching speed, and significantly increases transistor density over

previous 65nm technology

• Hyper-Threading Technology3 (two threads) provides high performance-per-watt efficiency in an in-order pipeline and increased system responsiveness in multi-tasking

environments. One execution core is seen as two logical processors, and parallel threads are executed on a single core with shared resources

• Enhanced Intel SpeedStep Technology reduces average system power consumption

• Enhanced low-power sleep states (C1E, C2E, C4E) are optimized for power by forcibly reducing the performance state of the processor when it enters a package low-power state

• Dynamic L2 cache sizing reduces leakage due to transistor sleep mode

• Intel Streaming SIMD Extensions (SSE) 2 and Intel SSE3 enable software to accelerate data processing in specific areas, such as complex arithmetic and video decoding

• FSB lane reversal enables flexible routing

• Execute Disable Bit4 prevents certain classes of malicious “buffer overflow” attacks









SPECIFICATIONS

Essentials
Status	Launched
Launch Date	Q2'08
Processor Number	N270
# of Cores	1
# of Threads	2
Clock Speed	1.6 GHz
L2 Cache	512 KB
Bus/Core Ratio	12
FSB Speed	533 MHz
FSB Parity	No
Instruction Set	32-bit
Instruction Set Extensions	SSE2, SSE3, SSSE4
Embedded Options Available	Yes
Supplemental SKU	No
Lithography	45 nm
Max TDP	2.5 W
VID Voltage Range	0.9V-1.1625V
1ku Bulk Budgetary Price	$44.00
Package Specifications
TJUNCTION	90°C
Package Size	22mm x 22mm
Processing Die Size	26 mm2
# of Processing Die Transistors	47 million
Sockets Supported	PBGA437
Halogen Free Options Available	Yes



Advanced Technologies
Intel® Turbo Boost Technology	No
Intel® Hyper-Threading Technology	Yes
Intel® Virtualization Technology (VT-x)	No
Intel® Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® Trusted Execution Technology	No
Intel® 64	No
Idle States	No
Enhanced Intel® Speedstep Technology	Yes
Intel® Demand Based Switching	No
Thermal Monitoring Technologies	Yes
Execute Disable Bit	Yes
