7.5hp Gasoline Engine Parts Mounting for Generator

7.5hp Gasoline Engine Parts Mounting for Generator thumbnail-1
7.5hp Gasoline Engine Parts Mounting for Generator thumbnail-2
7.5hp Gasoline Engine Parts Mounting for Generator photo-1
7.5hp Gasoline Engine Parts Mounting for Generator photo-2
US$ 50 - 130 MOQ: 10 Sets
Key Specifications
Get Latest Price
Condition:
New
Usage:
Other, pressure washer, cement mixers, compressors, mowers, vacuums, log spli
Fuel:
Gasoline
Contact Supplier Request Quote Chat Now
Chongqing Senci Import Export Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
MAIN PORT CHINA
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Usage Other, pressure washer, cement mixers, compressors, mowers, vacuums, log spli
Fuel Gasoline
Stroke 4 Stroke
Cylinder Single Cylinder
Cold Style Other, Air-cooled
Start Electric Start
Place of Origin Chongqing, China
Brand Name Senci
Model Number SC230
Dimension(L*W*H) 450x405x443mm
Weight 16kg
Certification CE, EPA,CARB,ROHS
Warranty 2 years
After-sales Service Provided Overseas third-party support available

7.5hp gasoline engine parts mounting for generator

Easy start | Stable output | Smooth operation | durable life



Product Description

MAIN FEATURES

  • OHV design, provides better fuel efficiency and cleaner emissions
  • Cast iron cylinder bore and steel forged crankshaft add protection under load, extending the engine life.
  • Sound-deadening alloy crankcase
  • Dual-element air cleaner
  • large indexable recoil starter and dual ball bearings make starting the engine at one pull.
  • Easy access throttle, choke and shutoff
  • Automatic low oil engine shutdown system
  • Muffler with heat shield
  • Horizontal shaft, an ideal multi-purpose replacement engine

 SPECIFICATION



Model No. SC230
Compression ratio 8.0:1
Horse Power 16HP
Bore×Stroke 73×58mm
Starting system Recoil/E-start
Displacement 223cc
Max Output/3600 4.5kW/3600rpm
Max Torque/2500 12.4N.m/2500rpm
Ignition type T.C.I
Fuel Consumption ≤374g/kW/h
Fuel Tank Capacity 3.6L
Oil capacity 0.6L
Dimensions(mm 415x355x395
Net Weight(kg) 16 kg
Loading Q'ty(20GP/40HQ) 770/1582



AMOUNTING DIMENSION

7.5hp gasoline engine parts mounting for generator

KEY PARTS

7.5hp gasoline engine parts mounting for generator
