Touch screen thermostat plastic cases with large LCD display, plastic touch screen cases
Main function
v Display the ambient temperature
v Set the control temperature
v Select the working mode
v Control the wind speed automatically or manually (expect T808D model)
v Blue backlight
v Screen cleaning function
v Low temperature protection function
v (turn off or set between 5°C and 17°C programmable)
v Sleeping function (turn off programmable)
v Key lock function (turn off programmable)
v Holding function without power (turn off programmable)
v Adjust the control return difference (1°C-3°C)
v Temperature calibration function
v Show the fault of sensing element
v Clock (12/24hours to select by software) and timing function ( 7days 4 periods or( 5+2) 4 periods programmable) (P model)
v Infrared remote control ( I model)
v 485MODBUS communication (N model)
Technical data
l Sensing element: NTC
l Measurement accuracy: 1 ° C
l Measurement range: 0 °C -99 °C
l Set-point range: 5 °C -35 °C
l Display: 66×51mmLCD
l Operation mode: touch screen
l Power self-consuming: <1W
l Case material: PC + ABS (flame retardant)
l Power supply voltage: 86Vac-260Vac 50/60Hz
l Power output: 220Vac 2A (resistive load)
220Vac 1A (inductive load)
l Dimension: 92mm×86mm×18mm
l Installation: standard 86 junction box
l Hole pitch: 60mm (standard)
l Wiring: terminals crimping
l Cross section of wire: 0.5mm²-2.5mm²
l Working environment: 0°C-45°C 5%RH-95%RH (non condensing)
l Storage temperature: -10°C-55°C
If you don't satisfied the above specification, please let us know your special requirement, we are very glad to customize your own thermostat according to your requirement.
