RAMWAY C Size Batteries 26500

RAMWAY C Size Batteries 26500 thumbnail-1
RAMWAY C Size Batteries 26500 photo-1
Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangxi, China
Brand Name:
RAMWAY
Model Number:
ER26500
Contact Supplier Request Quote Chat Now
Guangxi Ramway Technology Development Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangxi, China
Brand Name RAMWAY
Model Number ER26500
Battery Type LiSOCl2
Nominal Voltage Other, 3.6V
Size C
Nominal Capacity 9000mAh
  Electrical Charateristic
1.Nominal capacity:9000mAh
(At 1.0mA, 25 centigrade degree 2.0V cut off. The capacity restored by the cell varies according to current drain,
temperature and cut-off, For more severe conditions,consult Ramway.)
2.Rated voltage:3.6V
3.Max. recommended constant current:200mA
4.Max. pulse current capability:400mA
5.Dimension:26.2x50.5mm
6.Storage(recommended):Max.30 centigrade degree
(For more severe conditions,consult Ramway)
7.Operating temp. range:-60 to 85 centigrade degree( -76 to 185 Fahrenheit degree)
(Operation at temperature different from ambient may lead to reduced capacity and lower voltage plateau readings)
8.Typical weight:55g

  Key Features
1.High and stable operating voltage
2.Low self discharge rate(less than 1% after 1 year of storage at 25 centigrade degree)
3.Stainless steel container
4.Hermetic glass-to-metal sealing
5.Non-flammable electrolyte
6.Bobbin type
7.CE,SGS recognized,ISO9001 approved


  Main Application
1.Utility metering
2.Memory back-up
3.Alarms and security devices
4.Automotive electronics
5.Tollgate systems
6.Military electronics
7.Automatic meter reading
8.Professional electronics


  Warning
1.Fire, explosion and severe burn hazard;
2.Do not recharge, crush, disassemble,
  heat above 100 centigrade degree;
3.Do not solder directly to the cell.


  Solder and Connector
1.Lead wire:100mm;
2.Connector:XH-2P/2510-2P/SMP-2P/JST-SYP-2P/PH-2P/51005/51006/SMR-2P/5264.





Note

1.Free SAMPLE for testing(1-3pcs);

2.Factory price, FOB Shenzhen;

3.Connector or solder according to clients requirement;

4.If clients have special requirement on size of other dimension, please sent us the details or drawings;

5.Delivery: within 30 days after receiving the payment(this is for MOQ, any problem or special requests, contact us).

6.Provide OEM and ODM service.





RAMWAY C Size batteries 26500



RAMWAY C Size batteries 26500



RAMWAY C Size batteries 26500



RAMWAY C Size batteries 26500
