large size UV coating machine 1350mm UV lamination machine for advertising paper
About the UV coating machine
Main function:
Coating mainly on:laser printing,ink printing photo paper,art paper,gum stock.
Characteristics:
1.the photo coated can be dustproof,waterproof,scratch-resistance ,UV-resistance.
2.UV liquid can be attached to the paper,can not fall off once solidified by UV lamp.
3.The coating speed is fast, about 150-500sqm/h
4.The coat is low about 0.06USD, and the thickness of uv can be changeable.
5.Max. Coating width is 18-90Inch
6. The machine is free of cleaning, and can supplementing the uv liquid automatically
7.The device of powering off automatically when the temperature is too high, the operation is safe
8.Using superior lamp with 365 wavelength ensure to solidify quickly and thoroughly.
480, 650,800,900, 1350,1600,2000mm are also avaliable.
|
480 |
650 |
800 |
900 |
1350 |
1600 |
2000 |
Coating width |
480MM |
650mm |
800mm |
900mm |
1350mm |
1600mm |
2000mm |
Coating thinkness |
0.1-0.3mm |
0.1-0.3mm |
0.1-0.3mm |
0.1-0.3mm |
0.1-0.3mm |
0.1-0.3mm |
0.1-0.3mm |
Coating speed |
200-300M2 |
200-400M2 |
200-500M2 |
200-550M2 |
200-600M2 |
200-650M2 |
200-720M2 |
Dryer |
UV LAMP |
UVLAMP |
UV LAMP |
UV LAMP |
UV LAMP |
UV LAMP |
UV LAMP |
voltage |
AC220V/50HZ |
AC220V/50HZ |
AC220V/50HZ |
AC220V/50HZ |
AC220V/50HZ |
AC220V/50HZ |
AC220V/50HZ |
power |
3kw |
3.8kw |
4kw |
4.5kw |
8.6kw |
12.6kw |
12.6kw |
demension |
115*80*120 |
190*110*110 |
115*110*120 |
190*115*110 |
220*175*150 |
220*200*120 |
220*237*120 |
weight |
160KG |
230KG |
240KG |
300KG |
490KG |
660KG |
830KG |
we also offer UV liquid
1. glossy
2. matt
Double 100 Group was found in 2003, its is the biggest manufacurer of album making equipment and professional album comsumables supplier.
With more than 200 employee, the company own more than 1000sqm for laboratory building only for R&D research, more than 10,000 sqm workshop for euipment production and sepate longistic space for the fast and convenient dispatching goods.
