Automatic Welding Tractors in Arc welders
Special design for thick wire SAW,suitable for 3-5 wire and applicable to power source MZ-1000/1250
1 Modular construction to make dismounting easily ,meeting the actual requirements from various customers.
2 With four-wheel driving to realized stable moving .Six degree of freedom regulation meets any position request.
3 Combined wire feeding wheel improves using life and production efficiency.
4 Be suitable for welding carbon steel, stainless steel,copper and copper alloy.
5 Wire feeding unit adopts planetary reducer to make large moment and high stability.
6 Wire straighting unit keep the wire in good state.
7 Welding torch conduction adopts eccentric design,which realizes a strong conductivity.
Control box:simple circuit and easy maintenance.SCR speed-adjusting circuit is available in motor.
Power source:applicable to MZ series SAW power source.
From power source to welding head:15m(extending to 50m)
From power source to welding head:4m(extending to 50m)
|
A2 |
Wire diameter(mm) |
3.0-6.0(when MZ5-630 is the power,φ1.6-φ3.0) |
Arc strike model |
scraping ,fixed |
Welding speed range(cm/min) |
25-170 |
Wire feeding speed(m/min) |
0.2-1.7 |
Head moving range(mm) |
100*100 |
Head rotating angle |
360° |
Head weaving angle |
45° |
Head titling angle |
90° |
Flux hopper capacity(L) |
10 |
Wire reel capacity(Kg) |
25 |
Dimension L*W*H(mm) |
950*500*870 |
Weight(Kg) |
52 |
