Gray Iron Casting Front of Brake Discs,auto Brake Parts

1. Must meet G3000 for gray iron castings

2. Chemical Composition (Percent)

    * Total Carbon:             3.0 - 3.50%

    * Silicon:                       1.90 - 2.30%

    * Manganese:               0.60 - 0.90%

    * Phosphorus:               0.12% Max.

    * Sulfur:                          0.10% Max.

3. Microstructure:

    Graphite Structure: Predominantly type A, size 3-5.

    Matrix: Pearlistic with max.15 ferrite. Free from chill

4. Physical Properties

    Tensile Strength: Min. 200 N/mm

    Brinell Hardness: 190 ~ 230HB

1. Must meet G3000 for gray iron castings

2. Chemical Composition (Percent)

    * Total Carbon:             3.0 - 3.50%

    * Silicon:                       1.90 - 2.30%

    * Manganese:               0.60 - 0.90%

    * Phosphorus:               0.12% Max.

    * Sulfur:                          0.10% Max.

3. Microstructure:

    Graphite Structure: Predominantly type A, size 3-5.

    Matrix: Pearlistic with max.15 ferrite. Free from chill

4. Physical Properties

    Tensile Strength: Min. 200 N/mm

    Brinell Hardness: 190 ~ 230HB

1.package:

Neutral packing;

we can also pack according to customer's special request.

2.Shipping:

Within 45 days after receiving deposit.

1. Professional sales & service team. Over ten years experience in automobile and spare parts.

2. One-stop purchase with more options.
BRAKE parts: SUZUKI, TOYOTA, NISSAN, MAZDA, HYUNDA, KIA, GM, FORD, ECT,  CHANA, HAFEI, DONGFENG, WULING, CHERY, LIFAN GEELY, BYD, GREAT WALL, ZX, ZOTYE, JMC, JAC.
3. Good quality parts & competitive price.
4. Professional order operation procedures. A. All parts will be checked Part No., quality and Qty one by one in our factory. B. All parts will be repacked with high standard export, each part will have separate package and identification label with bar code.
5. Shorter delivery time.

Laizhou Haichen Machinery Co., Ltd is located in Shangdong province of China,specializing in producing brake discs, brake drums, brake pads and brake rotors. It was established in 2014. With a large workshop, professional production equipment, a world-leading technology and formulations. Blanks from the furnace to the production, processing, packaging and cleaning stop production, including the balance,the line of drilling, decromet, painting, galvanizing production and processing. OEM number or sample can be processed production. We have a strict and complete quality contral system which ensures that each product can meet customers' requiremnts.

     Our plant and equipment
Contact us


Early disc for pure iron, material selection and did not change much, but with advances in materials science, most modern motorcycleusing iron as a material for disc, now more common in stainless steel. Wide range of stainless steel, is excellent because of rigidcast iron stainless steel, you can reduce the thickness of plates,
integral braking system to reduce the weight. In addition, thedurability of stainless steel plate is also higher than that of cast iron plates.
In addition to stainless steel, dish surface is also a priority. In order to create sufficient hardness and toughess, complex heat treatment is required to ensure excellent mechanical properties, andunfortunately,
most metals heat treatment quality is unable todistinguish with the naked eye, even without expensive modification of the selling price on the heattreated plate endlessly.
In partanecdotal surface gold lustre dish, this will most likely be used toprevent Rust plated handle, this plating mill came off, is not apermanent treatment.
