2015 Newest 4 Usb Port Wall Charger

Name: 2015 Newest 4 Usb Port Wall Charger
Brand: LEAR
SKU: 120029403
Availability: InStock

Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

LEAR

Model Number:

K_USBH

Lear Electric (Kunshan) Industry Appliance Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name LEAR

Model Number K_USBH

Size 86*86cm

Max. Current 16A

Max. Voltage 250V

Mechanical Life More than 40,000 times On-Off

Product Description

_{Characteristics}

Knight series switches&sockets

Concise and simple profile, easy installation by adopting 1mm steel back frame, more closely fit into wall.

1,The first to create unique structure, more easy and quick for installation.

2,This switch only need one time take-down, and no need to consider the direction of button before installation.

3,Inside electric structure use top class Phosphor bronze, and brass for good electric conduction.

4,With steel framework for long durability and high quality PC for high temperature resistant, abrasion resistant & corrosion resistant.

5,Installation is quick and easy.

Main
Range of product	Knight series
Product code	K_USBH
Product name	newest 4 usb port wall charger
Product or component type	Outlet-socket
Device presentation	Complete mechanism
Complementary
Number of gangs	1 gang
Colour tint	White,Champagne,Silver
Projecting depth	8 mm
Device mounting	Flush
Mounting support	Wall mounted
Fixing mode	By screw M3.5
Fixing center	60.3 mm
Embedding depth	>= 35 mm
Rated current	16 AX
Rated operational voltage	250V AC
Network frequency	50-60HZ
Output current of USB port	2.1A
Output voltage of USB port	5V AC
Contacts material	Brass and phosphor bronze
Connections - terminals	Brass pillar terminal
Terminal identifier	L N E
Tightening torque	0.4 N.m
Clamping connection capacity	2.5 mm²
Width	86mm
Height	86mm
Material
Front-plate	Polycarbonate
Back-frame	1.2mm steel
Back-base	Polycarbonate
Conductive parts	Brass and phosphor bronze
Environment
Standards	IEC 60669-1
Ambient air temperature for operation	-5...40 °C
Relative humidity	0...95 %
Environmental characteristic	Indoor use
Contractual warranty
Period	10 YEARS
