15 Year Warranty High Quality Electric Switch and Socket

15 Year Warranty High Quality Electric Switch and Socket photo-1
US$ 0.6 - 12 MOQ: 2000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
LEAR
Model Number:
K_DB-10L
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin China
Brand Name LEAR
Model Number K_DB-10L
Size 86*86cm
Max. Current 10A
Max. Voltage 250V~
Mechanical Life More than 20,000 times



Product Description

Product  Feature

4mm ultra-slim profile electric switch and socket base on British standard for the modern home or commercial space. customized colours to steel switch plates that provide our widest variety of functions and value-added features.

15 year warranty high quality electric switch and socket 15 year warranty high quality electric switch and socket 15 year warranty high quality electric switch and socket

Knight series electric switch and socket

Outline size:

86X86mm
Installation size:60.3mm
Max current:10A
Max voltage:250V~
Standard:IEC60884
Mechanical lifetime:≥20,000
Protection grade:IP50
Fire-retardant grade of Plastic:UL94 V-0
Heat-resistant: 100°C / 1h
Damp Resistance: 48h > 5MΩ
Temperature Raise:≤ 45K
Insulation Resistance:≥5MΩ
Electric Strength:2000 V ~1 min
Earthing Provision:≤0.05Ω
Pull-out strength of Socket:between 9N and 50N

Materials

Front-Plate:Imported polycarbonate
Back-frame:1.2mm steel
Back-base:PA66
Contacts of switch:Extensive silver alloy point
Conductive parts:Copper and  Bronze
Terminal for Wiring:Copper pillar terminal



15 year warranty high quality electric switch and socket



Packaging & Shipping

Packaging&Shipping

Knight series electric switch and socket Packed by Colorful plastic bag,Colorful box and Carton

Quantity per Carton:12PCS/Box,120PCS/Carton
Carton Dimension:50.5x33x22.8cm
G.W/Carton:
N.W/Carton:
Quantity /20"Container:82400PCS,770Cartons
Quantity/40"Container:210000PCS,1750Cartons

15 year warranty high quality electric switch and socket



Our Customers

15 year warranty high quality electric switch and socket



Company Information

About us

LEAR has been a industry leader since 1984 in producing the safest electrical products such as wall switch and socket, Circuit breaker, Led light and so on for construction, commercial and household purpose.

LEAR(Kunshan) Company covers an aera of 36,000 square meter building size with about 1000 specialized staffs .We run the Quality Management systerms according to the ISO9001:2000 also certificated by CCC(China), CE, UL, SASO, PSB, IEC, etc.   Due to the increased market demand and the introduction to new market, we introduced German technology and equipment to enhance our quality and production capabilities.

Over the past 30 years, LEAR has built a global sales network, and established long-term strategic partnershipe with clients in South Afric, Pakistan, Sri Lanka, Malaysia, etc. Constantly seeking new opportunities to partner with organizaitons that are looking to expand into new markets. These companies appreciate the advantages of partnering with LEAR Group.



15 year warranty high quality electric switch and socket 15 year warranty high quality electric switch and socket

Our Services

Our Services

  • We provide 24 hours whole day online service. your inquiry will be on our prority attention.
  • More than 10 years warranty for all the our switch and socket.
  • We can customise your own brand imagin with professional team for design and promotion.
  • Our principle is one solo agent in a country, so protect your interst at the largest extent.

      Welcom you chose Knight series electric switch and socket ,we will provide more best support for you.
