Help CenterHonor Range 1 Gang 1 Way Switch
Negotiable
MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
LEAR
Model Number:
H_D
Size:
86mm*86mm
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
New Arrival Honor Range 2 Gang Electrical SwitchNegotiableMOQ: 1000 Pieces -
New Arrival Honor Range 2 Gang Light SwitchNegotiableMOQ: 1000 Pieces
-
New Arrival Honor Range 3 Gang Lighting SwitchNegotiableMOQ: 1000 Pieces
-
New Arrival Honor Range 4 Gang Rocker SwitchNegotiableMOQ: 1000 Pieces
-
New Arrival Honor Range 3 Gang Wall SwitchNegotiableMOQ: 1000 Pieces
Brand Name
LEAR
Model Number
H_D
Size
86mm*86mm
Max. Current
16AX
Max. Voltage
250V AC
Mechanical Life
40000 on-off times
Characteristics
|
Concise and simple profile, easy installation. Fire resistant by adopting high strength PC materisal. Inside electric struction using top class Phosphor copper for good electric conduction. |
Main | |
Range of product |
Honor series |
| Product code | H_D |
| Product name | |
| Product or component type | 16A |
| Device presentation | 250V~ |
| Complementary | |
| Switch function | 1-way |
| Actuator | Rocker |
| Pilot light |
None |
| Number of gangs | 1 gang |
| Colour tint | Silver stainless steel + Champagne |
| Projecting depth | 8 mm |
| Device mounting | Flush |
| Mounting support | Wall mounted |
| Fixing mode | By screw M3.5 |
| Fixing center | 60.3 mm |
| Embedding depth | >= 35 mm |
| Rated current | 10 AX |
| Rated operational voltage | 250 V AC |
| Network frequency | 50-60HZ |
| Contacts material | Brass and phosphor bronze |
| Connections - terminals | Brass saddle terminal |
|
Terminal identifier
|
COM L1 L2 |
| Tightening torque |
0.4 N.m |
| Clamping connection capacity | 2.5 mm² |
| Width | 86mm |
| Height | 86mm |
|
Material | |
| Front-plate | Polycarbonate with painting +stainless steel |
| Back-frame | 1.2mm steel |
| Back-base | Polycarbonate |
| Contacts material |
Silver |
| Conductive parts | Brass and phosphor bronze |
| Environment | |
|
Standards
|
IEC 60669-1 |
| Ambient air temperature for operation | -5...40 °C |
| Relative humidity | 0...95 % |
| Environmental characteristic |
Indoor use |
| Contractual warranty | |
| Period |
12 YEARS |
