Top Quality 2 Gang Lamp Socket

Name: Top Quality 2 Gang Lamp Socket
Brand: LEAR
SKU: 120024497
Availability: InStock

Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

LEAR

Model Number:

H_D2FZ2-13

Size:

146mm*86mm

Lear Electric (Kunshan) Industry Appliance Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Brand Name LEAR

Model Number H_D2FZ2-13

Size 146mm*86mm

Max. Current 13AX

Max. Voltage 250V AC

Mechanical Life 40000 times

Product Description

_{Characteristics}

Honor series switches&sockets

Concise and simple profile, easy installation.

Fire resistant by adopting high strength PC materisal.

Inside electric struction using top class Phosphor copper for good electric conduction.

Main
Range of product	Honor series
Product code	H_D2FZ2-13
Product name	2 gang lamp socket
Product or component type	Socket-outlet
Device presentation	Complete mechanism
Outlet standard	Universal
Complementary
Outlet poles configuration	2P+E
Pilot light	None
Number of gangs	2 gang
Colour tint	Stainless steel+champagne color
Projecting depth	8 mm
Device mounting	Flush
Mounting support	Wall mounted
Fixing mode	By screw M3.5
Fixing center	120.6 mm
Embedding depth	>= 35 mm
Rated current	13 AX
Rated operational voltage	250 V AC
Network frequency	50-60HZ
Contacts material	Brass and phosphor bronze
Connections - terminals	Brass pillar terminal
Terminal identifier	N L E
Tightening torque	0.4 N.m
Clamping connection capacity	2 x 4 mm² 3 x 2.5 mm²
Width	146mm
Height	86mm
Material
Front-plate	Polycarbonate
Back-frame	1.2mm steel with insulation varnish
Back-base	Polycarbonate
Switch contacts material	Silver
Conductive parts	Brass and phosphor bronze
Environment
Standards	MS 589 SS 145 BS 1363
Ambient air temperature for operation	-5...40 °C
Relative humidity	0...95 %
Environmental characteristic	Indoor use
Contractual warranty
Period	10 YEARS
