ORBITA hotel safe lock for hotel system
Main Features:
Weight:3.8 kgs/pc
350mm*78mm*17mm
Static Load<15Ua
Working Load:200Ma-400Ma
Humidity:20%-80%
Working tempreture:-50°C-80°C
Stainless steel &Brass Material, moisture proof, fire retardant
Satin Chrome/golden finish, PVD coating lasting 10 years
ANSI/European Standard mortise
Inside Dead Bolt. Inside handle retracts latches and deadbolt.
SLE4442 IC card, 10000 times life, high security,compatible with Energy Saver.
Override Computer Key for Emergency use, individual/master cylinder
Personalized Locking System and cylinder cover
Step by step installation software, easy operation. OEM locking system available.
Classified Access Authorization for safety management.
General master card, building master card, floor master card, guest card
All card with validity, guest card expires automatically at default check out date and time.
Lost guest card suspension simply by issuing a new guest card or Cancel card.
Multiple operators with different card issuing authorization
Lock operation record printable. 240 pcs or more
Receptionist card issuing records printable
Power:6 pcs #5 AA Alkaline battery. 18 months’ duration
Low Battery Voltage warning. (Lower than 5.5 V.)
Self Error detecting by LED and “beep”.
Improper lock warning
Wireless stand alone lock realizes 95% of on line lock function.
Passage function available
Swimming Pool/Sauna Room/Tennis court/Gym access lock function
Interface with most of the PMS system (Fidelio Registered)
CE FCC
Lock Indication Symbols
No. |
Status |
Beep Indication |
LED indication(flash) |
1 |
Correct |
1 |
green LED, 1 |
2 |
Slant Latches get Stuck |
Continuous |
Red LED keeps flashing |
3 |
Error |
2 |
Red LED 3 |
4 |
Clear Authorization |
1 Long |
Green LED 1 |
5 |
Wrong Area |
3 |
Yellow LED 2 |
6 |
Wrong time |
3 |
Yellow LED 3 |
7 |
Card Suspending Error |
3 |
Yellow LED 4 |
8 |
Illegal Card |
4 |
Yellow LED 3 |
9 |
Illegal card |
4 |
Yellow LED 4 |
10 |
Clock card over time |
4 |
Red LED |
11 |
Deadlocked |
2 |
Red LED |
12 |
Non Access Setting |
5 |
Red LED |
13 |
Cancel |
3 |
Red LED |
Problem |
Possible Reason |
Solution |
Red light blinks two times and two beeps. |
a) The card is not issued for this door. b) The staff/maintenance card has lost its validity after being used for a few times. |
Use the correct card; Or issue a new maintenance card |
Red light blinks three times and three beeps. |
The time of the card does not match that of the lock. |
Synchronize the time either/both of the card or/and the lock. |
Red light blinks four times and four beeps. |
The lock has not been authorized. |
Authorize the lock with a card or a PP. |
Red light blinks five times and five beeps. |
The card has been suspended. |
Issue a new card. |
Red light blinks six times and six beeps. |
The lock has been deadbolted. |
If need be, gain access to the room with a master card, an emergency card or a PP. |
Red light blinks seven times and seven beeps. |
The lock has been blocked by a block card. |
If need be, gain access to the room with a master card, an emergency card or a PP, or unblock the lock with the lock card. |
Red light blinks eight times and eight beeps. |
The lock has been authorized by another system. |
Use cards issued by that system; Or perform mandatory authorization if need be. |
INSTALLTION:
