Specifications
led highbay high power led highbay light;Led high bay light 100w;made in aluminum
high efficiency
led highbay
Super Bright High Power LED Highbay Light, LED High Bay light is widely used in warehouse, store, gym, churches, assembly factory. The common high bay light requires replacement bulb, the LED Highbay Light is a lifetime LED, most importantly, it save up to 80% electricity bills.
This is a high power industrial LED high bay light, using only one single 92W high power LED. The LED is connected to the shell reflector which enables the heat emitting through the aluminum efficiently. This lamp is easy to be installed with the hook. The silver aluminum reflector is a wide design, about 500mm diameter wide, hook it above 6 meters it can give about 53.8 Lux illuminance bright.
Light colors are optional in Warm White, Pure White and Cool White, different color has different color temperature.
100W LED High Bay Light Features:
1. Stable, using single High Power LED lighting souce.
2. Integrative heat sink design, the LED connected with the metal reflector, never over heat.
3. High energy saving, compared with other traditional high bay light, it saves up to 80% power.
4. Instant light start, no warming up, no buzzling.
5. Safety, CE, RoHS approval.
100W LED High Bay Light Specifications:
Input Voltage |
AC85V--265V |
Frequency |
50Hz--60Hz |
||
Distortion |
≤ 9% |
Power Factor |
>0.9 |
||
Power Efficiency |
>83% |
LED Quantity |
1 pc LED |
||
LED Power |
92W |
Working Voltage |
DC30-36V |
||
System Power |
100w |
Led Efficiency |
60-100LM/W |
||
Light Efficiency |
>80% |
Uniformity |
>0.4 |
||
Light Distribution |
Simmental /Round Beam |
Junction Temp. |
≤80 |
||
Working Temp. |
-40--+55 |
Storage Temp. |
-25--+65 |
||
IP Grade |
IP65 |
Life-span |
>30000H |
||
Lamp Shell Color |
Black/Silver (Optional) |
Overall Size |
Φ500mm * H466mm |
||
Net Weight |
5.48kgs |
Certificate |
CE |
||
|
Led Initial Flux |
Warm White |
7100 Lm |
Illuminance |
6M High |
53.8Lux |
Pure White |
7500 Lm |
8M High |
24.6 Lux |
||
Cool White |
7200 Lm |
10M High |
13.6 Lux |
||
|
Effective Area |
6M High |
Φ10M Circle Spot |
Color Temp |
Warm White |
2700K-3900K |
8M High |
Φ16M Circle Spot |
Pure White |
3900K-6000K |
||
10M High |
Φ21M Circle Spot |
Cool White |
6000K-7000K |
||
|
CRI
|
Warm White |
Ra>68 |
Wire Connect |
Brown Wire |
L |
Pure White |
Ra>75 |
Blue Wire |
N |
||
Cool White |
Ra>75 |
Y |
|||
