Product Description
♦ Layer: 6 layer ♦ Thickness: 1.6mm ♦ Material: FR4 ♦ Copper thickness: 35um ♦ Mini Hole: 0.2mm ♦ Mini Width/space: 0.1mm/0.1mm ♦Surface Treatment: Lead-Free HASL ♦ Solder mask: red/ Green
|
Electronic PCBA PCB assembly, PCB PCBA,PCB design in Sograce
Maximum Process PCB board Capability of Our Company
Files |
Gerber, Protel, Powerpcb, Autocad, Cam350, etc |
Material |
FR-4, Hi-Tg FR-4, Lead free Materials (RoHS Compliant) , CEM-3, CEM-1, Aluminium, High frequency Material (Rogers, Teflon, Taconic) |
Layer No. |
1 - 30 Layers |
Board thickness |
0.0075"(0.2mm)-0.125"(3.2mm) |
Board Thickness Tolerance |
±10% |
Copper thickness |
0.5OZ - 4OZ |
Impedance Control |
±10% |
Warpage |
0.075%-1.5% |
Peelable |
0.012"(0.3mm)-0.02’(0.5mm) |
Min Trace Width (a) |
0.005"(0.125mm) |
Min Space Width (b) |
0.005"(0.125mm) |
Min Annular Ring |
0.005"(0.125mm) |
SMD Pitch (a) |
0.012"(0.3mm) |
pcb with green solder mask and LF-FREE surface finishing BGA Pitch (b) |
0.027"(0.675mm) |
Regesiter torlerance |
0.05mm |
Min Solder Mask Dam (a) |
0.005"(0.125mm) |
Soldermask Clearance (b) |
0.005"(0.125mm) |
Min SMT Pad spacing (c) |
0.004"(0.1mm) |
Solder Mask Thickness |
0.0007"(0.018mm) |
Hole size |
0.01"(0.25mm)-- 0.257"(6.5mm) |
Hole Size Tol (+/-) |
±0.003"(±0.0762mm) |
Aspect Ratio |
6:01 |
Hole Registration |
0.004"(0.1mm) |
HASL |
2.5um |
Lead free HASL |
2.5um |
Immersion Gold |
Nickel 3-7um Au:1-3u'' |
OSP |
0.2-0.5um |
Panel Outline Tol (+/-) |
±0.004''(±0.1mm) |
Beveling |
30°45° |
V-cut |
15° 30° 45° 60° |
Surface finish |
HAL, HASL Lead Free, Immersion gold, Gold plating, Gold finger, immersion silver, immersion Tin, OSP, Carbon ink, |
Certificate |
ROHS ISO9001:2000 TS16949 SGS UL |
Special requirements |
Buried and blind vias, Impedance control, via plug, BGA soldering and gold finger |
Quote requirement for pcb and pcb assembly:
1.Circuit board assembly fabrication:
Onestop pcb assemblies service, PCB design, PCB layout, PCB manufacturing,
PCB Assemblies, components sourcing, PCBA Function Test, design solution.
2.Quote Needed:
1.PCB Gerber File;
2.Bom List for PCB Assembly;
3. Send us a sample of PCBA to make the exactly same for you.
4. Test Method for PCB Assembly.
3.PCB+COMPONENTS+SMT the whole service with top quality and very competitive price for you;
OEM design and custom made products are welcomed.
PCB Assembly Technical Request:
- Professional surface-mounting and Through-hole Technology
- Various sizes like 1206, 0805, 0603 components SMT Technology
- ICT ( In Circuit Test), FCT ( Functional Circuit Test) Technoloty
- PCB Assembly with UL, CE, FCC, RoHs approval
- Nitrogen gas reflow soldering technology for SMT
- High standard SMT & Solder Assembly Line
- High density interconnected board placement technology capacity
Our Certifications:
Packaging & Delivery
|
Packaging Details:
|
The electronic PCBA PCB assembly, PCB PCBA,PCB design in Sograce is:
|
|
Delivery Detail:
|
3-5 working days for sample,7-10 working days for mass order
|
1.Which type of PCBs do you expert in?
We are specialized in producing Singe-side PCB,Double-side PCB, Multilayer PCB,Aluminium PCB,Spray Tin PCB,Immersed Gold PCB, etc.
2.What is your Lead time?
usually 3-7 days for PCBA sample, 5-10 days for mass production.
3.What is your testing policy and how you controle the quality?
For sample, usually tested by flying probe; for PCB Volume over 3 square meters, usually tested by fixture, this will be more faster. Due to there’s many steps to PCB production, we usually do inspection after every step.
4.What is your package?
With Inner vacuum package and out carton.
5.Will you allow me to put several part number together into one panel?
Yes, this is usually happen in we factory, this way can help customers reduce some cost and to a certain degree, it can help reduce some assembly cost.
6.What is your minimum order quantity?
We have no limitation on MOQ, prototype, medium volume and large volume are all acceptable.
7.Are my design files safe when I submit them to you for manufacturing?
Any customer’s file will be protected very well here in our factory and we will not let any third party know. We can sign NDA with you.
Sograce International Corporation Limited
is a professional PCB manufacturer for poducing all kinds of single side, double-side and multilayer pcb,
also provide assembly service with 10 years experience.We have a variety of advanced production equipments,
excellent engineering and technical personnels, accompany with the mature management and service system.
Our pcbs meet IEC,IPC,DIN,MIN standard, behaves ISO-9001 quality system ,UL and Rohs certificate.
Fast lead time and competitive price with high quality are our advantages. PCB lead time is within 10days,
and most can be within 7days. We also established a prototype team to develop customer’s prototype needs.
prototype lead time often can be within 3days.
