Product Description
♦ Layer: 1-16 layer ♦ Thickness: 1.6mm ♦ Material: FR4 ♦ Copper thickness: 35um ♦ Mini Hole: 0.2mm ♦ Mini Width/space: 0.1mm/0.1mm ♦Surface Treatment: Lead-Free HASL ♦ Solder mask: red/ Green
|
Electronic PCBA PCB assembly, PCB PCBA,PCB design in Sograce
Quote requirement for pcb and pcb assembly:
1) Gerber file and Bom list
2) Clear pics of pcba or pcba sample for us
3) Test method for PCBA
PCB Assembly Technical Request:
- Professional surface-mounting and Through-hole Technology
- Various sizes like 1206, 0805, 0603 components SMT Technology
- ICT ( In Circuit Test), FCT ( Functional Circuit Test) Technoloty
- PCB Assembly with UL, CE, FCC, RoHs approval
- Nitrogen gas reflow soldering technology for SMT
- High standard SMT & Solder Assembly Line
- High density interconnected board placement technology capacity
Maximum Process PCB board Capability of Our Company
Files |
Gerber, Protel, Powerpcb, Autocad, Cam350, etc |
Material |
FR-4, Hi-Tg FR-4, Lead free Materials (RoHS Compliant) , CEM-3, CEM-1, Aluminium, High frequency Material (Rogers, Teflon, Taconic) |
Layer No. |
1 - 30 Layers |
Board thickness |
0.0075"(0.2mm)-0.125"(3.2mm) |
Board Thickness Tolerance |
±10% |
Copper thickness |
0.5OZ - 4OZ |
Impedance Control |
±10% |
Warpage |
0.075%-1.5% |
Peelable |
0.012"(0.3mm)-0.02’(0.5mm) |
Min Trace Width (a) |
0.005"(0.125mm) |
Min Space Width (b) |
0.005"(0.125mm) |
Min Annular Ring |
0.005"(0.125mm) |
SMD Pitch (a) |
0.012"(0.3mm) |
pcb with green solder mask and LF-FREE surface finishing BGA Pitch (b) |
0.027"(0.675mm) |
Regesiter torlerance |
0.05mm |
Min Solder Mask Dam (a) |
0.005"(0.125mm) |
Soldermask Clearance (b) |
0.005"(0.125mm) |
Min SMT Pad spacing (c) |
0.004"(0.1mm) |
Solder Mask Thickness |
0.0007"(0.018mm) |
Hole size |
0.01"(0.25mm)-- 0.257"(6.5mm) |
Hole Size Tol (+/-) |
±0.003"(±0.0762mm) |
Aspect Ratio |
6:01 |
Hole Registration |
0.004"(0.1mm) |
HASL |
2.5um |
Lead free HASL |
2.5um |
Immersion Gold |
Nickel 3-7um Au:1-3u'' |
OSP |
0.2-0.5um |
Panel Outline Tol (+/-) |
±0.004''(±0.1mm) |
Beveling |
30°45° |
V-cut |
15° 30° 45° 60° |
Surface finish |
HAL, HASL Lead Free, Immersion gold, Gold plating, Gold finger, immersion silver, immersion Tin, OSP, Carbon ink, |
Certificate |
ROHS ISO9001:2000 TS16949 SGS UL |
Special requirements |
Buried and blind vias, Impedance control, via plug, BGA soldering and gold finger |
1.Circuit board assembly fabrication:
Onestop pcb assemblies service, PCB design, PCB layout, PCB manufacturing,
PCB Assemblies, components sourcing, PCBA Function Test, design solution.
2.Quote Needed:
1.PCB Gerber File;
2.Bom List for PCB Assembly;
3. Send us a sample of PCBA to make the exactly same for you.
4. Test Method for PCB Assembly.
3.PCB+COMPONENTS+SMT the whole service with top quality and very competitive price for you;
OEM design and custom made products are welcomed.
Packaging & Delivery
|
Packaging Details:
|
The electronic PCBA PCB assembly, PCB PCBA,PCB design in Sograce is:
|
|
Delivery Detail:
|
3-5 working days for sample,7-10 working days for mass order
|
Sograce International Corporation Limited
is a professional PCB manufacturer for poducing all kinds of single side, double-side and multilayer pcb,
also provide assembly service with 10 years experience.We have a variety of advanced production equipments,
excellent engineering and technical personnels, accompany with the mature management and service system.
Our pcbs meet IEC,IPC,DIN,MIN standard, behaves ISO-9001 quality system ,UL and Rohs certificate.
