94v0 Infrared Led Pcb Board Printed Circuit Board

Name: 94v0 Infrared Led Pcb Board Printed Circuit Board
Brand: sograce
SKU: 119980709
Availability: InStock

US$ 0.20 - 0.20 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

sograce

Model Number:

aluminum pcb

Sograce International Corporation Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name sograce

Model Number aluminum pcb

Number of Layers Other, 2 LAYER

Base Material Aluminum Base

Copper Thickness 1oz

Board Thickness 1.6mm

Min. Hole Size 0.10mm

Min. Line Width 0.2MM

Min. Line Spacing 0.1MM

Surface Finishing HASL/OSP/ENIG

FR-4 material led pcb pcb design from Sograce

Product Description

94v0 infrared led pcb board printed circuit board

Layer: 2Layers Material: FR4
Board Thickness: 1.6mm Solder Mask: Green

Copper Thickness: 2oZ Size: 117mm*165mm

Min.Line Width: 0.075mm Min.Line Spacing: 0.075mm

Surface Treatment: Lead-Free HASL Certificate: UL,RoHs,SGS

Files	Gerber, Protel, Powerpcb, Autocad, Cam350, etc
Material	FR-4, Hi-Tg FR-4, Lead free Materials (RoHS Compliant) , CEM-3, CEM-1, Aluminium, High frequency Material (Rogers, Teflon, Taconic)
Layer No.	1 - 30 Layers
Board thickness	0.0075"(0.2mm)-0.125"(3.2mm)
Board Thickness Tolerance	±10%
Copper thickness	0.5OZ - 4OZ
Impedance Control	±10%
Warpage	0.075%-1.5%
Peelable	0.012"(0.3mm)-0.02’(0.5mm)
Min Trace Width (a)	0.005"(0.125mm)
Min Space Width (b)	0.005"(0.125mm)
Min Annular Ring	0.005"(0.125mm)
SMD Pitch (a)	0.012"(0.3mm)
pcb with green solder mask and LF-FREE surface finishing BGA Pitch (b)	0.027"(0.675mm)
Regesiter torlerance	0.05mm
Min Solder Mask Dam (a)	0.005"(0.125mm)
Soldermask Clearance (b)	0.005"(0.125mm)
Min SMT Pad spacing (c)	0.004"(0.1mm)
Solder Mask Thickness	0.0007"(0.018mm)
Hole size	0.01"(0.25mm)-- 0.257"(6.5mm)
Hole Size Tol (+/-)	±0.003"(±0.0762mm)
Aspect Ratio	6:01
Hole Registration	0.004"(0.1mm)
HASL	2.5um
Lead free HASL	2.5um
Immersion Gold	Nickel 3-7um Au:1-3u''
OSP	0.2-0.5um
Panel Outline Tol (+/-)	±0.004''(±0.1mm)
Beveling	30°45°
V-cut	15° 30° 45° 60°
Surface finish	HAL, HASL Lead Free, Immersion gold, Gold plating, Gold finger, immersion silver, immersion Tin, OSP, Carbon ink,
Certificate	ROHS ISO9001:2000 TS16949 SGS UL
Special requirements	Buried and blind vias, Impedance control, via plug, BGA soldering and gold finger
