High quality 5630 addressable dmx rgb led strip light
- 20000 Square Meter / Square Meters per Month
- shenzhen
- Credit Card
- USB Relay Output Module PCB Board for Home Automation
- PCB Roger Circuit Board with cheap cost & Fast supply
- Cheap cost Rogers PCB production , pcb sample
- Fast Supply Rogers 4350 PCB Circuit Board Prototype and mass pcb production
- High quality Rogers Printed Circuit board with fast supply , rogers material in stock
- 2 layers Taconic Material PCb /Special material pcb circuit board provided
Product Details
Place of Origin: | Guangdong, China | Brand Name: | sograce | Model Number: | aluminum pcb |
Number of Layers: | Other, 2 LAYER | Base Material: | Aluminum Base | Copper Thickness: | 1oz |
Board Thickness: | 1.6mm | Min. Hole Size: | 0.10mm | Min. Line Width: | 0.2MM |
Min. Line Spacing: | 0.1MM | Surface Finishing: | HASL/OSP/ENIG |
Product Description
FR-4 material led pcb pcb design from Sograce
High quality 5630 addressable dmx rgb led strip light
Layer: 2Layers Material: FR4
Board Thickness: 1.6mm Solder Mask: Green
Copper Thickness: 2oZ Size: 117mm*165mm
Min.Line Width: 0.075mm Min.Line Spacing: 0.075mm
Surface Treatment: Lead-Free HASL Certificate: UL,RoHs,SGS
Files | Gerber, Protel, Powerpcb, Autocad, Cam350, etc |
Material | FR-4, Hi-Tg FR-4, Lead free Materials (RoHS Compliant) , CEM-3, CEM-1, Aluminium, High frequency Material (Rogers, Teflon, Taconic) |
Layer No. | 1 - 30 Layers |
Board thickness | 0.0075"(0.2mm)-0.125"(3.2mm) |
Board Thickness Tolerance | ±10% |
Copper thickness | 0.5OZ - 4OZ |
Impedance Control | ±10% |
Warpage | 0.075%-1.5% |
Peelable | 0.012"(0.3mm)-0.02’(0.5mm) |
Min Trace Width (a) | 0.005"(0.125mm) |
Min Space Width (b) | 0.005"(0.125mm) |
Min Annular Ring | 0.005"(0.125mm) |
SMD Pitch (a) | 0.012"(0.3mm) |
pcb with green solder mask and LF-FREE surface finishing BGA Pitch (b) | 0.027"(0.675mm) |
Regesiter torlerance | 0.05mm |
Min Solder Mask Dam (a) | 0.005"(0.125mm) |
Soldermask Clearance (b) | 0.005"(0.125mm) |
Min SMT Pad spacing (c) | 0.004"(0.1mm) |
Solder Mask Thickness | 0.0007"(0.018mm) |
Hole size | 0.01"(0.25mm)-- 0.257"(6.5mm) |
Hole Size Tol (+/-) | ±0.003"(±0.0762mm) |
Aspect Ratio | 6:01 |
Hole Registration | 0.004"(0.1mm) |
HASL | 2.5um |
Lead free HASL | 2.5um |
Immersion Gold | Nickel 3-7um Au:1-3u'' |
OSP | 0.2-0.5um |
Panel Outline Tol (+/-) | ±0.004''(±0.1mm) |
Beveling | 30°45° |
V-cut | 15° 30° 45° 60° |
Surface finish | HAL, HASL Lead Free, Immersion gold, Gold plating, Gold finger, immersion silver, immersion Tin, OSP, Carbon ink, |
Certificate | ROHS ISO9001:2000 TS16949 SGS UL |
Special requirements | Buried and blind vias, Impedance control, via plug, BGA soldering and gold finger |
High quality 5630 addressable dmx rgb led strip light
Packaging Details: | 1:Vacuum for inner Packing. 2:Carton for outer Packing. 3:Then to a wooden Case. |
Delivery Detail: | 3 To 7 Days |
High quality 5630 addressable dmx rgb led strip light
We specialize in:
PCB design, PCB layout, PCB manufacturing, PCB Assemblies,
One-stop services from PCB to PCB assembly
components sourcing, PCBA Function Test, design solution.
Electronic testing circuit board or PCBA
Eleectronic manufacturing service
PHOTOS SHOW
CHOOSE US =CHOOSE BEST SERVICE
If you have any request please contact us,we will try our best to satisfied you
Contact Us
- Sograce International Corporation Limited
- Contact nameNick Chen
- Phone86-755-29309731
- AddressBuilding A503-504,2013 Maker Park,NO.108,Lijia Rd,Longgang District Shenzhen,Guangdong
