Large Capacity Granule Packing Machine
- Qingdao Shanghai Tianjin etc
- T/T
You May Like
Product Details
| Condition | New | Application | Food, Beverage, Commodity, Medical, Chemical | |
| Packaging Type | Case | Packaging Material | Wood | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 220V | Power | 4.2KW | |
| Place of Origin | Henan, China | Brand Name | CW | |
| Model Number | CW-403 Granule packing machine | Dimension(L*W*H) | 1040mm*860mm*2040 mm | |
| Weight | 500KG | Certification | CE,BV,ISO | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1 Material.SS3042.PLC control
3. bag making , computation, filling, sealing, cutting,
Double side Full automatic Packing machine
for granula packing
| Item | Full automatic packing machine |
| Model | CW-1802 |
| Material | Stainless steel 304 |
| Number of head | Single head |
| Application | powder |
| Pack size (length) | 50mm-170mm |
| Pack size(width) | 30mm-135mm |
| Packing capacity | 28-60 packs/min |
| Filling range | 5-300ml |
| Voltage and frequency | 200v 50hz |
| Power | 1.5kw |
| Dimension | 1000mm(L)*860mm(W)*1900mm(H) |
| Weight | 300kg |
| Sealing type | Double side sealing |
| Warranty | 12 months |
| After sale service | Life time |
Three side Full automatic Packing machine
for granula packing

| Item | Full automatic packing machine |
| Model | CW-1803 |
| Material | Stainless steel 304 |
| Number of head | Single head |
| Application | powder |
| Pack size (length) | 50mm-170mm |
| Pack size(width) | 30mm-135mm |
| Packing capacity | 28-60 packs/min |
| Filling range | 5-300ml |
| Voltage and frequency | 200v 50hz |
| Power | 1.5kw |
| Dimension | 1000mm(L)*860mm(W)*1900mm(H) |
| Weight | 300kg |
| Sealing type | three side sealing |
| Warranty | 12 months |
| After sale service | Life time |
Three side Full automatic Packing machine
for granula packing
| Item | Full automatic packing machine |
| Model | CW-1804 |
| Material | Stainless steel 304 |
| Number of head | Single head |
| Application | Powder |
| Pack size (length) | 50mm-170mm |
| Pack size(width) | 30mm-135mm |
| Packing capacity | 28-70 packs/min |
| Filling range | 5-300ml |
| Voltage and frequency | 200v 50hz |
| Power | 1.5kw |
| Dimension | 1000mm(L)*860mm(W)*1900mm(H) |
| Weight | 300kg |
| Sealing type | Four side sealing |
| Warranty | 12 months |
| After sale service | Life time |
Full automatic high speed Packing machine
for granula packing
| Item | Full automatic packing machine |
| Model | CW-383 |
| Material | Stainless steel 304 |
| Number of head | Single head |
| Application | Powder |
| Pack size (length) | 55mm-110mm |
| Pack size(width) | 30mm-80mm |
| Packing capacity | 50-108 packs/min |
| Filling range | 1-40ml |
| Voltage and frequency | 200v 50hz |
| Power | 1.5kw |
| Dimension | 600mm(L)*790mm(W)*1740mm(H) |
| Weight | 300kg |
| feature | high speed |
| Warranty | 12 months |
| After sale service | Life time |
Full automatic high speed Double cutter Packing machine
for granula packing
| Item | Full automatic packing machine |
| Model | CW-404 |
| Material | Stainless steel 304 |
| Number of head | Single head |
| Application | Powder |
| Pack size (length) | 55mm-110mm |
| Pack size(width) | 30mm-80mm |
| Packing capacity | 70-140 packs/min |
| Filling range | 5-40ml |
| Voltage and frequency | 200v 50hz |
| Power | 1.5kw |
| Dimension | 1040mm(L)*860mm(W)*2040mm(H) |
| Weight | 520kg |
| cutter | double |
| Warranty | 12 months |
| After sale service | Life time |
Full automatic Large capacity Packing machine
for granula packing
| Item | Full automatic packing machine |
| Model | CW-688 |
| Material | Stainless steel 304 |
| Number of head | Single head |
| Application | Powder |
| Pack size (length) | 50mm-300mm |
| Pack size(width) | 30mm-200mm |
| Packing capacity | 20-40 packs/min |
| Filling range | 5-1000ml |
| Voltage and frequency | 200v 50hz |
| Power | 1.8kw |
| Dimension | 1100mm(L)*1000mm(W)*2100mm(H) |
| Weight | 350kg |
| feature | large capacity |
| Warranty | 12 months |
| After sale service | Life time |
Application :
Wide range covers Food , Chemical, Medicine, etc.
Powder should be inattentive , low moisture and low viscid .
Available for small and medium package.
Main structures :
1. Automatic filling system
2. Automatic weighing balance
3. Automatic belt conveyor
4. Automatic sewing machine
5. Electric control cabinet
Working process:
Manual Bag placing→Automatic filling→Automatic weighing
→Automatic bag conveyer→Automatic bag sewing
For More information of our packing machine, please kindly click contact us !
Xinxiang Chenwei Machinery Co., Ltd is a manufacturer of screening machines,conveying machine,packing machines ,crushers with well-equipped testing equipment and strong technical force.
With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in mining, pharmacy, food, chemical, metal powder and other industries.

Guarrantee and after sale service :
One year guarantee for the whole machine
24hours technical support by email
24 hours online service
Instruction in English language
User manual in PDF and Printed copy
Installation videos
Six free services including regular follow up services:
1.FREE technical enquiries
2.FREE repairs during warranty
3.FREE special services for key projects
4.FREE inspection upon delivery
5.FREE operation and repair training
6.FREE period follow-up and maintenance service
Q: What factors I need to get a quotation?
1. Material (name) that you want to process, with the density, water content(%).
2. The necessary process capacity (per hour)
3. Material contact part, SS304, SS316L and Q235 for option.
Q: Do you accept special orders?
A: Special order is also available because we have our own factory ,which is a leading manufacturer in this area with 30 years’experience.
Q:What is the real delivery time of your factory?
A: 7 to 15 days for general series products, meanwhile, batches products & customized products would need 30 days to 60 days based on different situations.
Q: How do you ensure the quality of your products?
A: Generally, our equipments are the most durable type in the industry, this is also the feature of the label impression of CWJX for most of our customers at home or abroad. With our experienced quality control team, we are trying to offer most of our customers the product with bset quality. However, we do recognized that there do have small amount of the product which may got faulty or damaged for different reasons.
Q: How do your after-sale service work if the product got damaged?
A: In the gurantee time 12 months, our general after-sale service is changing the damaged parts for the customer, but if the damage could be repaired by slight cost, we would wait for the customer's bill for the fix cost and refound this part of cost.(note: Vulnerable parts do not include.)
Q: How could I trust your promise?
A:
Firstly, you may check the assessment on our website certified by the appraisal agency Bureau Veritas;
secondly, we attend at least 4 to 6 international industry exhibitions held in China annually, like the Food Ingredients China, China International Battery Fair, CPhI, ICSE BioPh China, ICIF China, etc. We usually met our customers there for negotiation;
Thirdly, company inspection always available, if you have any representative or you would like to come to our site, we offer free shuttle from Zhengzhou airport to our company, welcome your visit.
