X1 Special Design OEM and ODM 32bit Wired Barcode Scanner

Name: X1 Special Design OEM and ODM 32bit Wired Barcode Scanner
Brand: NETUM
SKU: 119956935
Availability: InStock

US$ 1 - 30 MOQ: 1 Piece

Key Specifications

Products Status:

Stock

Type:

Barcode Scanner

Scan Element Type:

Other, laser, CMOS

Guangzhou Yuanji Electronic Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Products Status Stock

Type Barcode Scanner

Scan Element Type Other, laser, CMOS

Colour Depth 32 Bit

Interface Type USB

Max Paper Size A4

Optical Resolution 3mil

Scan Speed 260times/sec

Brand Name NETUM

Model Number X1

Place of Origin China

Product Description

Netum X1 32bit USB interface laser wired barcode scanner

Specifications
Type of illuminant:		650nm laser		Scanning method:		Manual
CPU:		32bit		Fall test:		2 meter
Bit error rate (BER):		1/8 million		Materials:		electronic
Safety performance		Meet the Grade II National Criteria for Laser Safety
Supported interfaces		USB
Transmission rate		RS232 Baudeate:2400-38400
Resolution (pcs0.9)		0.076mm(3mil)
Barcode types		1D codes, such as EAN-8,EAN-13,UPC-A,UPC-E,Code 39,Code 93,Code 128,EAN128,Codaber,Industoal 2 of 5, Interleave 2 of 5,Matrix 2 of 5,MSI, Chinese postcode etc.
Depth of field		10-800mm
decode speed		260 times/second
Reading preciseness		0.40-0.825mm
Reading distance		10-800mm
Reading angle of elevation		60°
Reading angle of dip		45°
Light intensity		Daylight, 4000Lux
Electromagnetic interference		Complying with en50081, par1 criteria
External electromagnetic interference resistance		Complying with en50081, par1criteria
Dustproofing and waterproofing		Complying with en50081, par1 criteria
Eelectrical
Power voltage:		DC 5V		Static current:	36mA
Working current		57mA
Environmetal
Operating humidity:	5%-85%		Operating temperature:			-20°C-45°C
Storage humidity:	5%-85%		Storage temperature:			-20°C-45°C
Safety performance	ROHS class 2 laser product, FCC class B and CE
