poplar film faced plywood
1. Technical Data
| data | specification |
| size | 1220x2440mm |
| thickness | different thickness available, from 12mm to 21mm |
| core | poplar, birch, hardwood, combined or requested by client |
| glue | mr/melamine/wbp phenolic glue |
| film | black/brown/red chinese film or dynea film |
| grade | A/A grade or requested |
| packing | inner with plastic bag, outerside with 3mm plywood/carton board, then fasten with 3x6 steel strip, then packed with pallets. |
| application | concrete formwork for construction |
2.Specification
| thickness(mm) | layers | standard size | large size | ||
| min. (mm) | max.(mm) | min.(mm) | max.(mm) | ||
| 9 | 7 | 8.5 | 9.5 | 8.2 | 9.5 |
| 12 | 8 | 11.5 | 12.5 | 11.2 | 12.5 |
| 15 | 9-10 | 14.5 | 15.5 | 14.2 | 15.5 |
| 18 | 11 | 17.5 | 18.5 | 17.2 | 18.5 |
| 21 | 13 | 20.2 | 21.5 | 20.2 | 21.5 |
3. Moisture (8-14%) & density:
| products | weight (kgs/m3) |
| birch | about 700kgs/m3 |
| combined | 500-700kgs/m3 |
| poplar | about 510kgs/m3 |
4. Conserve and maintain:
storage:
always clean and repair the formwork panels before storage, the formwork should then be stacked off the ground on level supports and under cover. framed formwork panels should be stacked alternately face and back to back to avoid face damage by bolts etc. if panels are wet, do not allow them to dry too rapidly.
sealing of edges:
phenolic film faced plywood edges are fully sealed by the factory and it is the most important that all edges remain sealed. to obtain full value from a phenolic film faced plywood sheet any recut edges should sealed as soon as possible with water proof paint sealing of holes.
any hole made in film faced formwork panels should also be sealed to prevent water entering. if water does enter it may cause swelling around the holes.
cleaning and repair:
to obtain full life, cleaning should be carried out immediately after each use. phenolic film faced plywood may be wiped with release agent or cleaned with water and stiffbrush. it may be necessary to use a hard wood scraper but care should be taken not to damage the plywood face. do no use a wire brush or sharp metal scraper to dislodge hardened concrete.
Linyi Jiale Wood Co., Ltd. is a professional film faced plywood factory located in Linyi City, China, which is a famous plywood production base in China, it was established on 2006, we have 3 production line, covering the area of 10 thousand square meters.
Our management principal is "supplying good and stable quality products at most reasonalbe price", "To satisfy our customers" is our work mission.
We warmly welcome all the customers from both domestic and abroad to come to our factory for a visit and business discussion.
Kindly please feel free to add my contact skype lyjialewood for further information, with thanks.
