Help CenterGlass Sand Packing Machine
Related Products
Specifications
It is sand packaging machineglass sand packing machine
sand bagging machine
for packing garnet sand, color sand, etc.
Instruction:
It's glass sand packing machine, sand packaging machine, sand bagging machine applicable for faster packaging garnet sand, color sand, glass sand, silica sand, quartz sand, garnet sand, Filtration Sand, fine sand, etc. The bag must be supplied and placed to clamp device by manual.
This LCS-Y2 model packing machine is made with integrative combined double weighing and filling system, so it’s just like two packing machines working together. Therefore, it’s more efficient .
Technical Parameter:
Model |
LCS-Y2 |
|
Weighing Range |
5~10, 10~25, 25~50 kg/bag, etc. customized |
|
Packing Speed Capacity |
Max. 480~500 bags/hour |
|
Weighing Accuracy |
±0.2 % FS |
|
Applications |
Free flowing granules, pellet, bead, prill, powder, etc. |
|
Package Pattern |
Single or multi-layer open mouth bag or valve bag |
|
Package Bag Size |
900 x 575mm(adjustable) |
|
Package Material |
Poly woven bag, kraft paper bag, PP bag, PE bag, etc. |
|
Air Source |
Pressure |
0.5 ~ 0.6MPA |
Consumption |
1.6M3/h |
|
Power Supply |
Voltage |
AC220V/380V, 50/60Hz, as per local voltage |
Power |
~ 2.0 KW |
|
Self Weight |
~ 1000KG |
|
Remarks: The actual packing speed & precision is subject to the unit weight per bag & materials' feature. | ||
