Igbt Inverter Ac/dc Tig Welder
US$ 60 - 100
MOQ: 15 Pieces
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
WM inverter welder
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Frequency Welder for SaleUS$ 60 - 100MOQ: 15 Pieces -
Triple Function Mig Welding Wire 1.2mmUS$ 60 - 100MOQ: 15 Pieces
-
Plastic Portable InverterUS$ 60 - 100MOQ: 15 Pieces
-
Single Phase Inverter Circuit BoardUS$ 60 - 100MOQ: 15 Pieces
-
High Frequency Welder With 2t/4tUS$ 60 - 100MOQ: 15 Pieces
Condition
New
Place of Origin
Guangdong, China
Brand Name
WM inverter welder
Model Number
TIG160ACDC inverter welder
Arc Current
10-200A
Pulse Frequency
50/60hz
Pilot Arc Current
10-160A welding machine
Rated Duty Cycle
60%
Motor Type
DC Motor
Dimensions
400*145*300mm
Usage
manufacturing of hardware,decorations,pipeline install,metalplates
Voltage
230v
Power(W)
3.3kva
Certification
CE and Rohs
Warranty
2 years
After-sales Service Provided
Engineers available to service machinery overseas
Specifications: igbt inverter ac/dc tig welder
| Input Voltage(V) | AC230V±10%(single phases) |
| Input voltage current | 15 |
| Power capacitance(KVA) | 3.3 |
| Rated output current(A) | 160 |
| Output current range(A) | 10-160 |
| No load voltage(V) | 45 |
| Working voltage(V) | 16.4 |
| Pre flow(s) | 0~2 |
| Output frequency(Hz) | 60 |
| Clean width(%) | 20~80 |
| Slop-down time(s) | 0~5 |
| Post-flow time(s) | 2~10 |
| Duty cycle imax(25℃) | 60% |
| Duty cycle 100%(25℃) | 120A |
| Arc-starting | HF vibration |
| Efficiency(%) | 85 |
| Power factor | 0.7 |
| Insulation class | F |
| Protection Class | IP21 |
| Welding thickness(mm) | 0.5~10 |
| Size (mm) | 493*330*320 |
| Weight(KG) | 19 |
welding machine,welding machine, welding machine, welding machine, welding machine, welding machine
Accessories: Standard: 1pcs of 4M SR-26 integrated Tig torch, 1 set of 300A Earth clamp + 3m 16mm2 Cable + KDP-16A, 1PCSKDP-16A, 1pc 1.6*150mm tungsten electrode
Optional: 1: TIG package: 200A electrode holder clamp and 3m 16mm2 Cable
2: Argon gas regulator
3: Custom-designed luxury case
Standard: HF/Scratch TIG
Current knob
TIG200AII postflow knob 0-10s
MMA
O.C.Led light (O. C& O.H alarm)
Power indicator
Optional: steel case
ABS face and rear
2T/4T function
110/220V dual-voltage
digital display
igbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welderigbt inverter ac/dc tig welder
