Help CenterPulse AC/DC Tig 250
US$ 60 - 100
MOQ: 15 Pieces
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
WM inverter welder
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Triple Function Module Mig Welding ProcessUS$ 60 - 100MOQ: 15 Pieces -
Digital Displa Plasma Cutter UsedUS$ 80 - 200MOQ: 15 Sets
-
Giant Mma-200 Inverter Arc WelderUS$ 60 - 100MOQ: 15 Pieces
-
Arc Gouging MZ Inverter for 1000/1250US$ 60 - 100MOQ: 15 Pieces
-
Single Phase Small Electric WelderUS$ 60 - 100MOQ: 15 Pieces
Condition
New
Place of Origin
Guangdong, China
Brand Name
WM inverter welder
Model Number
TIG250PACDC inverter welder
Arc Current
10-220A
Pulse Frequency
50/60hz
Pilot Arc Current
10-220A welding machine
Rated Duty Cycle
60%
Motor Type
DC Motor
Dimensions
560*365*356mm
Usage
manufacturing of hardware,decorations,pipeline install,metalplates
Voltage
400v
Power(W)
6.3kva
Certification
CE and Rohs
Warranty
2 years
After-sales Service Provided
Engineers available to service machinery overseas
Specifications: Pulse AC/DC Tig 250
| Input Voltage(V) | AC380V±10%(3phases) 50/60Hz |
| Input voltage current | 19 |
| Power capacitance(KVA) | 8.9 |
| Rated output current(A) | 300 |
| Output current range(A) | 15~300 |
| No load voltage(V) | 45 |
| Working voltage(V) | 22 |
| Pre flow(s) | 0~2 |
| Output frequency(Hz) | 60 |
| Clean width(%) | 20~80 |
| Slop-down time(s) | 0~5 |
| Post-flow time(s) | 2~10 |
| Duty cycle imax(25℃) | 60% |
| Duty cycle 100%(25℃) | 240A |
| Arc-starting | HF vibration |
| Efficiency(%) | 85 |
| Power factor | 0.93 |
| Insulation class | F |
| Protection Class | IP23 |
| Welding thickness(mm) | 0.5~15 |
| Size (mm) | 560*365*355 |
| Weight(KG) | 37 |
welding machine,welding machine, welding machine, welding machine, welding machine, welding machine
Features
·Has TIG & MMA functions
·2T/4T function
·Smooth arc and stable welding performance
·DC TIG function ideal for welding carbon steel.stainless steel.
Copper and non-ferrous metals
·AC function ideal for aluminum & aluminum alloy welding
·Digital meter display
Standard:
Optional:
·TIG Package 8: 300A Eletrode clamp and 3m 35mm² Cable
·Pedal control box
·Remote control box
·Water cooler 8L/9L
Standard:
·Pulse TIG
Pulse frequency knob
Current knob
AC DC
·MMA
·TIG
