bag chemical powder filling machine
I. Application
This machine is especially designed for packing 0.5-50kg powder of bad mobility, such as feed, fertilizers, rubber powder, PE powder, moringa powder etc. into open-mouth bags like plastic woven bags, Kraft bags, sacks, paper-plastic compound bags and barrels, cartons.
Our LCS-LX Single Screw Feeding Bagging Machine is especially suitable for the manual filling of small production quantities. Packing machines with low production outputs do not normally require fully automatic packing systems. Even so they still demand precise filling of their products.
II. Working Principle
First, the bag need be applied manually to the filling spout and the filling process is started by a push-button.Your material will firstly go to the hopper and then be filled into the bags via the screw feeding parts. The filling flow is controlled by the frequency-change screw’s (auger’s) rotating speed. When the bag is filled fully, the bag clamping device will automatically open and the bag will be conveyed to the sewing system for sealing.
III. Working Process
Manually bag placing → Automatic filling → Automatic weighing → Automatic conveying → Automatic sealing (sewing,heating or weld) → next process
IV. Feature
Your benefits due to our experience:
u Clean bag filling
Due to product-specially chosen filling spout with all-side clamping jaws
u Space saving
Due to compact machine design
u Cost saving
Due to stable operation and low maintenance costs
u Easy handling
Due to easy and intuitive operational menu with “weight input” “weight display” “time display”
Due to clear operator guidance, easy cleaning and maintenance
u High weight accuracy: ±0.2%FS
Due to coarse and fine flow filling controlled by one frequency-change screw’s (auger’s) rotating speed
Due to the use of the Canadian General Measure or METTLER TOLEDO weighing controller and OMISEO (USA) load cell sensors
u Good product protection
Due to project-specially selected bag closure, e.g. sewing, welding or hot-melt sealing
And the Optional device:
1. Dust removal device. The working environment will be more hygienic if the dust removal device is added.
2. Customized designs for explosion-proof, dust-proof, anti-corrosion, dust collection, etc.
V. Technical parameters
Model |
LCS-LX |
Weighing Range |
1-5, 5-10, 10-25, 25-50 Kg/bag, customized needs |
Precisions |
±0.2%FS |
Output Capacity |
180-240bags/hour (depending on the material properties, bag sizes and bag mouth sizes) |
Power |
1.5+1.3 kw |
Power Supply |
AC220/380V, 50/60Hz, 3 phase;will make as per local Electrical system |
Air Power |
0.4~0.6 Mpa ( need 170ml, or 0.17 m³ or 8kg air compressor) |
Working temperature |
-20-40℃ |
Working humidity |
<95% (no condensate water) |
Dimension |
3000×700×2800mm, subject to the real machine. |
Belt conveyor Dimension |
3000*400mm, for reference, subject to the real machine. |
Weight |
300~350kg, subject to the real machine. |
To see more about our machine video on Youtube:
/channel/UCg94kU3IB6c_co4waj6xb5A
Main Configuration List
n Material Level Sensor : KOYO or OMRON (Japan)
n Weighing Controller :F701D, Mettler-Toledo or Canada General Measure brand.
n Load Cell Sensors :OMISEO or Mettler-Toledo
n Cylinder : SC of Airtac (Taiwan)
n Electromagnetic Valve:Airtac (Taiwan)
n Separator :Airtac (Taiwan)
n Triple Part :Airtac (Taiwan)
n Motor :Wan Nan (Anhui, China)
n Import Bearing :NSK (Japan)
n Electric Component :Schneider or CHINT (Wenzhou, China)
n Construction Steel :Product touching parts by SUS304 and other parts by mild steel painted.
