Lifting and Sliding Parking System

Lifting and Sliding Parking System thumbnail-1
Lifting and Sliding Parking System thumbnail-2
Lifting and Sliding Parking System thumbnail-3
Lifting and Sliding Parking System thumbnail-4
Lifting and Sliding Parking System photo-1
Lifting and Sliding Parking System photo-2
Lifting and Sliding Parking System photo-3
Lifting and Sliding Parking System photo-4
US$ 2,000 - 4,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Type:
Parking Lift
Height (mm):
5000 mm
Width (mm):
1850mm
Contact Supplier Request Quote Chat Now
Anhui Huaxing Intelligent Parking Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai nanjing
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Parking Lift
Height (mm) 5000 mm
Width (mm) 1850mm
Place of Origin Anhui, China
Brand Name Huaxing
Model Number PSH
Warranty 10 Years
About Us

1.Huaxing Metal Structure Co., Ltd., as the main investment party of Huaxing Parking, has Grade-I steel structure manufacturing and installation qualification, ten years of manufacturing and sales experience and more than 8 million square meters of steel structure construction cases. So we can guarantee the permanent beauty of the machinery garages in the aspects of derusting, paint spraying and welding of steel structures.


2. Huaxing Parking has established long-term closely cooperative relationships with Hefei University of Technology, Chinese Academy of Sciences (Hefei) and advanced parking equipment manufacturers in Japan, South Korea, etc. It has more than 60 professional technicians, including 5 professor senior engineers and 25 engineers. Most of them have above 5 years of experience in parking equipment industry. Most of the workers committed to steel structures and electrical accessories have above 3 years of experience, skilled and experienced.

3.Huaxing continuously makes improvements in the aspect of technology and challenges zero defect in the aspect of quality. Since 2008, it has recruited technical experts and management elites with high salary from Shuangliang, Yee Fung, XJ, Hanguang, South Korea YKY, etc. Especially, several patents (such as advanced safe, automatic and flexible loading technology, falling preventive device and stroke control devices, etc.) fill in the blanks in national market. Now the team is stable and in good spirit, which is the basic guarantee of long-term development.

We can design, manufacture, install puzzle type automated parking system, as well as provide professional afterservice, which saves parking space efficiently.

It is one structure in which parking zone consists of 2 or more levels and all parking zones in the levels with exit can be used as both entrance and exit. It is designed to park vehicles by moving pallets in up-down and left-right directions. It is classified into 2-level, 3-level, 4-level, 5-level, 6-level and PIT types according to the number of the levels. And also it can be divided into single-row type and multiple-row type according to the way of arrangement used. The whole procedure is automatically completed by PLC.

Our advantages in this field:

1, Self designing, manufacturing, installing, and also researching and developing automatic parking system, with powerful technical advantages;

2, cooperating with the world-renowned parking system manufacture, Korea Dongyang Co., having foreign advanced technologies;

3, High specialization, advanced processing equipment/machinery;

4, Having our own installation engineering team without outsourcing to install, supervising and managing efficiently; Adjustment of automatic products is fulfilled by Senior engineers having accomplished many parking system projects with rich experience and good understanding about the products;

5, Using high quality steel materials, special-made driving chain, and special-made motor for parking system, which bring our parking systems long life-scan, steady & safe running, low accident rate, etc.

Technical Characteristics:

1, Three running models: IC card, auto-control, manual-control;

2, Powerful function, with real-time supervision and long-distance diagnosis through internet, so technicians in Shenzhen can solve, in real time, the site-malfunctions and problems in different locality;

3, Choosing best parts and fittings in the world: Mitsubishi FX controller, C-Clink general wire, Honeywell limit switch, etc.

4, Taking out cars quickly & continuously, emptying parking system quickly in case of emergency;
5, Safe, reliable, mature system;


Technical information:
Modes and types of parking facility PSH, Puzzle type
Spec. of available cars Length 5200 mm
Width 1950 mm
Height 1850 mm
Weight 2200 kg
Lift Hoisting motor 2.2kw
Transverse motor 0.2kw
Electric specification Motor controller IGBT INVERTOR
Mode of control PLC mode  (standard)
Mode of operation touch-screen or PC   (optional)
Power Dynamical power 3 phase, AC 380V, 50Hz
Safety device entrance guide lamp, inner radiation lamp, vehicle guide mirror
Inspection sensor on the car position of entrance floor
Sensor in the front of hoisting steel rope
Anti-transfinite system of lift and cart-table
Emergency stop system
Safe running inspection system




Projects

Lifting and Sliding Parking System

Our Service


1) Lifetime Service ,one year warranty for all steel structures and electric parts
2) Proive engineer to guide installation
3) Provide technical consulting and design
