automatic bagging machine for dry chemical powder
Specifications
It is completed
automatic packing machine
applicable for packing
granules or particulate
matter in industries.
Applications:
It is Completed Automatic Packing Machine applicable for packing granules or particulate matter in industries such as chemistry, fertilizer, grain, food, feed, medicine, construction materials industry, etc.
Main Components:
1. Automatic quantity-fixed balance 2.Automatic bag-supply section
3. Optional section such as air compressor 4.Automatic bag-clamped section
5. Automatic belt conveyor 6.Automatic sewing / sealing machine
7. Automatic bag-backwards section 8.Electrical instrument control cabinet
Characteristics:
- Picking bag, feeding bag, filling material, weighing in , sewing / sealing bag, bag-backwards and bag transmission are finished completely automatically.
- Adopting PLC to guarantee the reliability of control
- Adopting high-precision transducer and intelligent instrument to guarantee the accuracy and speed of weight
- Adopting touch screen with trouble display and help system for easy operation.
- Adopting imported pneumatic components features compact structure, reliable performance and convenient maintenance.
- The sewing / sealing machine is an imported machine.
Main Technical Parameter:
Model: MZDP
Packing Scope: 5~10, 10~25, 25~50 (KG) (adjustable as per requirement)
Weight Accuracy: ±0.2%FS
Packaging Material: Open mouth bag
Bag Size: 950×650mm(adjustable as per different weight )
Air Pressure: 0.6 (Mpa)
Air Consumption: 0.7 (m3/min)
Power: 8~16 (KW)
Total weight: 25000 (KG)
To see more about our machine video on Youtube:
/channel/UCg94kU3IB6c_co4waj6xb5A
Main Configuration List
n Material Level Sensor : KOYO or OMRON (Japan)
n Weighing Controller :F701D, Mettler-Toledo or Canada General Measure brand.
n Load Cell Sensors :OMISEO or Mettler-Toledo
n Cylinder : SC of Airtac (Taiwan)
n Electromagnetic Valve:Airtac (Taiwan)
n Separator :Airtac (Taiwan)
n Triple Part :Airtac (Taiwan)
n Motor :Wan Nan (Anhui, China)
n Import Bearing :NSK (Japan)
n Electric Component :Schneider or CHINT (Wenzhou, China)
n Construction Steel :Product touching parts by SUS304 and other parts by mild steel painted.
Contact: Eunice
E-mail: eunice at go2mj dot com Tel: 86-18068286380
Skype: eunicemengmengkp QQ: 975326099
