Help CenterHigh Quality ATV Rubber Track Drive Systems
Related Products
-
Super Quality Mini Snow TrackUS$ 12 - 30MOQ: 1 Piece -
Hot Sale!!! Mini Snowblower Rubber TrackUS$ 12 - 30MOQ: 1 Piece
-
Hot Sale!!! Mini Snow Removal Rubber TrackUS$ 12 - 30MOQ: 1 Piece
-
High Quality Small Robot/Snowblower Rubber TrackUS$ 12 - 30MOQ: 1 Piece
-
High Quality Mini Track SnowblowerUS$ 12 - 30MOQ: 1 Piece
Specification of rubber track conversion system kits
- Warranty: 13months/1500 Operating Hours
- Type:Crawler
How to Measure Rubber Tracks?
To check for the size of your existing rubber track you will need to measure followings.
1. Measure the width of the track in millimeters or we can do the conversions for you. (1 inch = 25.4 millimeters)
2. Measure the distance from the top of the center of one link (metal piece that engages with the sprocket on the track) to the top of the center of the next link (in millimeters or we can do the conversions for you). This distance is known as the pitch of the track.
3. Count the total number of links (also called metal pieces or lugs) inside of the track.
The measurement of a track is Width x Pitch x Links.
Interchangeable Track Designs
Interchangeable guide type replacement tracks were originally designed for use on equipment with undercarriages designed for steel tracks but now most can interchange with rubber. Interchangeable type rubber tracks have pitch measurements (this is the distance from the center of one metal link to the center of the next metal link) of 47, 48, 48.5, 60, 52.5, 53, 54, 54.5, 55, 55.5, 56, 71, 72, 72.5, 75.5, 76, 81, 83.5, 92, 96 millimeters.
Conventional Track Designs
Conventional guide type replacement tracks are designed for use on equipment with undercarriages designed for rubber tracks. Conventional type tracks have pitch measurements (this is the distance from the center of one metal link to the center of the next metal link) of 60, 72, 84, 86, 87, 90, 100, 125 and 150 millimeters.
Rubber Track Tread Patterns and OEM Track Sizes
A wide range of track designs and track patterns are available for specific machine applications and working conditions. Ask one of our professional sales associates which patterns are available for your machine.
Track Patterns
Roller Type
Engineering track technical parameters
Agricultural technical parameters
Clip-on technical parameters
We're manufacturer!
Contact us to Get a Quote!
NO OBLIGATION!
