Specifications
led 5050 smd:1--Power:6.5W
2--Input voltage:90-277Vac
3--Warranty:3 years
4--Certification:CE,ROHS,FCC,PSE,TUV
led 5050 smd:
1-Input : 90-264V
2-Lumen : 125Lm/W
3-CRI : 85Ra
4-PFC : 0.95
led 5050 smd Spcifications:
| Item No:CCB-G24052P5-01 | Color Temp: White/Warm White/R/G/B |
| Description: 6.5W Led PL light | Work Temp: -35~55oC |
| Input Voltage: AC 90-264 V | Operating Humidity: ≤85% |
| Power: 6.5W | Life Span: 80,000Hrs |
| Luminous Flux: 127LM/W | Appearance: polishing |
| LED Qty: 52 PCS | Meterial: high quality Aluminum Alloy |
| Dimension: 35x35x138mm | Warranty: 3 years |
| Color-Rendering Index: ≥80Ra | Power factors:≥0.95 |
Other power general data:
| Led PL light | Input Voltage | Lumen output | CRI | PFC |
| 3.0W | 90-264V | 310Lm | 82 | 0.9 |
| 4.0W | 90-264V | 450Lm | 82 | 0.91 |
| 5.0w | 90-264V | 570Lm | 82 | 0.92 |
| 6.7W | 90-264V | 810Lm | 82 | 0.94 |
| 8.2W | 90-264V | 900Lm | 82 | 0.94 |
| 10.0W | 90-264V | 1050Lm | 80 | 0.95 |
Led 2G11 PL Light data:
| Led 2g11 light | Input Voltage | Lumen output | CRI | PFC |
| 13.5W | 90-264V | 1610Lm | 82 | 0.94 |
| 15.5W | 90-264V | 1830Lm | 82 | 0.94 |
| 17.5W | 90-264V | 2230Lm | 82 | 0.95 |
| 20.5W | 90-264V | 2450Lm | 82 | 0.95 |
Other g24 lamp models
1.3W, 4.5W 7W 8W 9W, 10W, 18W, 20W etc.
2. Dimmable type or non-dimmable led PL light.
3. eye protecting Led PL light
4. Led 2G11 socket light.
g24 lamp main features:
1. High efficiency, easy operation save energy, suitable for office usage.
2. The light decay is very small (less than 1% after 2000hrs working hours)
3. Unique patented heat sinking design
4. CE and RoHS certified
5. Led efficiency above 120Lm/W
6. Warranty for 3 years
About us:
China CCB Led Ltd is a 7 years manufactuering of led products in China
and continuely pay attention to high quality led products design and manufacturering.
Through all those years' support from partners all around, we have let millions
families and companies to enjoy the advance of new technology. Welcome you
join us to a better future.
g24 lamp:
Application:
1. led PL light for Under cabinet lighting
2. for Art lighting
3. for Boat lighting, accent lighting
4. for Recess lighting,shelf lighting
5. for meeting hall, shopping malls, etc.
6. to replace Philips Osram convertional PL light
7. for street lighting.
How we manufacturing:
What certificates we have got:
Our factory:
Our test data are more than 125Lm/W
Thanks very much for your time and welcome your inquiry at any time.
