Specifications
12v led downlight1.12-24v input
2.CE,RoHS FCC certificates
3.Lifespan:80,000hrs
4.3 years warranty
12v led downlight
cree 12v led downlight 3 year warranty
12w cree dimmable led downlight 1250Lm
1.AC90-277V input
2.CE,RoHS FCC certificates
3.Lifespan:80,000hrs
4.3 years warranty
12v led downlight Details:
| Model | CCB-DL01201-H-01 | ||||
| Desc | 12w cree dimmable led downlight |
||||
| Led Quantities | 12*1W | ||||
| Led | US CREE/OSRAM/Edison | ||||
| Illuminance | 120 - 130Lm/Led | ||||
| Input Power | 90 ~ 277Vac | ||||
| Led Driver | PFC>0.98, Power Efficiency > 0.88 | ||||
| Color Tempeture | 2800 - 7000K | ||||
| CRI | 75 - 85 | ||||
| Working Temp | -35 ~ 55 degree | ||||
| Working Humidity | 10% - 85% | ||||
| Storage Temp | -40 ~ 80 degree | ||||
| Beam Angle | 8/15/25/38/45/60/90/105 | ||||
| Life Span | >80,000hrs | ||||
| Fixture Size | φ140*66mm | ||||
| Instrallation Way | Recessed | ||||
| Drilling hole | 125mm | ||||
12v led downlight models:
| Model: | Power | Lumen Output | Drilling Hole |
| CCB-DL00301-H | 3W | 275 | 75mm |
| CCB-DL00501-H | 5W | 460 | 95mm |
| CCB-DL00601-H | 6W | 550 | 95mm |
| CCB-DL00701-H | 7W | 630 | 95mm |
| CCB-DL00901-H | 9W | 920 | 125mm |
| CCB-DL01201-H | 12W | 1150 | 125mm |
| CCB-DL01501-H | 15W | 1350 | 145mm |
1.3*1W; 3*2W; 3*3W; 5*1W; 5*2W; 6*1W; 7*1W; 9*1W; 12*1W; 1*5W; 1*10W,etc.
2. Dimmable type or non-dimmable led downlight.
3.Remote controlled led downlight
Our 12v led downlight advantage:
1- With high quality series led we make color tempeture more even;
2- By cooperating with EURO/USA power company, we make
our driver more efficiency and long life;
3- With different test machines and processes we make the products
are of 0 defective rate to arrive at your hand;
4- With care & heart we handle them like BABIES;
5- With 8 years experience in foreign, we are sure to let you gain more;
6- With intensive online technical support, we will answer you question
within 4 hours;
12v led downlight main features:
1. High efficiency, save energy, suitable for down light Minimal maintenance cost
2. The light decay is very small (less than 1% after 2000hrs working hours)
3. Unique patented heat sinking design
4. CE and RoHS certified
5. Working temperature rising: less than 15°C
6. Led efficiency above 100Lm/W
7. Warranty for 5 years
About us:
We are the professional Led manufacturer in China and has 8 years
Experience in R&D produce many kinds of Led tube, led bulb,Led
downlight etc.We only pay attention to high quality led products.
All our products have passed CE,RoHs,FCC,PSE,UL certificates
and spread through USA,Canada,Germany,U.K.Japan,and Australia,etc.
Our test are from international certified lab:
Other dimmable led downlight models:
Our cree dimmable Led downlight Packing:
Our cree dimmable led downlight certificates:
Thanks very much for your time.Any question, pls feel free to
contact us.best regards
