Energy saving High safety eel feed hammer mill
- 100 Unit / Units per Month
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Type: | Wood hammer mill | Use: | Raw materials grinding | Certification: | CE& ISO9001 |
Place of Origin: | Jiangsu, China | Brand Name: | YONGLI | Model Number: | SWFL128 |
Condition: | New | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Energy saving High safety eel feed hammer mill
Features:
1. Unique Feeding Design, the feeding inlet is made at the side of the device to make feeding easily.
2. The shell is welded by steel plate, the site in the crush room which connects to the materials all use the wearable and commutative parts and double wear plate.
3. The motor and rotor are installed in the same heavy-duty base, using coupling direct drive, the rotor are checked by dynamic balance, and can work forward and reverse, the hammers are arranged symmetrically.
4. The second grinding designed for grinding chamber, the output can increase 15% even particle size.
5. Two kinds of gap between beaters and screeners through changing position of beater are used for coarse and fine grinding.
6. The smaller gap between beater and screeners can be used for grinding coarse and fine materials.
7. Applicable for raw materials grinding such as corn, Chinese sorghum, wheat, crumbled cake-shaped material etc.
8. It can also grind the raw materials: woodchips, straw, EFB, rice husk, grass, sunflower, grass, woodchips, wood shaving, olive slag, paper etc.
Working principle
The material needs to be ground be fed into the top intake port through the feeding device which matches this hammer mill, enters into the grinding room from the left or right side through intake direction plate. Under the beating of high speed rotating hammer and the rubbing effect of screen, material is grinded gradually, and discharged from the seat discharging port through screen holes under the effect of centrifugal force and airflow.
Main Parameters
Specification | YHM56×36 | YHM56×40 | YHM60×45 | YHM60×60 | YHM60×80 | ||
Rotor diameter (mm) | 560 | 560 | 600 | 600 | 600 | ||
The grinding chamber width (mm) | 360 | 400 | 450 | 600 | 800 | ||
Spindle speed (r / min) | 2950 | 2950 | 2980 | 2980 | 2980 | ||
The hammer line speed (minutes / seconds) | 86 | 86 | 94 | 94 | 94 | ||
The number of hammer | General smash | 20 | 24 | 44 | 48 | 60 | |
Fine grinding | 40 | 48 | 80 | 88 | 110 | ||
Main power(KW) | 22/30 | 30/37 | 45~75 | 45~90 | 110 | ||
Universal Anti-knock Pad | 6 | 6 | 8 | 9 | 8 | ||
Dimensions | Length (mm) | 1440 | 1650 | 1930 | 1981 | 2300 | |
Width (mm) | 800 | 800 | 838 | 838 | 1000 | ||
Height (mm) | 1000 | 1000 | 1194 | 1194 | 1200 | ||
Aspirating capacitym3/min | General smash | 18 | 22 | 40 | 48 | 70 | |
Fine grinding | 22 | 25 | 45 | 53 | 75 | ||
grinding machine for sale
Grinding production line:
YONGLI COMPANY:
Jiangsu Yongli Machinery Co., Ltd. is a qualified manufacturer which specializes in developing, producing and marketing top-class machinery equipment. Now we focus on pellet mill, hammer mill, mixer, drum dryer, wood chipper, packing machine, etc. and turn key projects.
The advantages of our quick installation, such as beautiful appearance, flexible operation, stable performance and low operational cost are accepted by more and more customers. We own an outstanding R&D team and a strict & scientific management system, which enable us to supply high quality & convenient turn-key projects to all of our customers.
We have successfully produced over 1,000 turn key projects to clients, which make us one of the biggest manufacturers and the most powerful factories for biomass machinery. We have already sold our machines to over 80 countries, they are: Latvia, Russia, Slovenia, France, Italy, Tunisia, New Zealand, Australia, Colombia, Brazil, Uruguay, Vietnam, Thailand, Malaysia, Singapore, Indonesia, Algeria, the UAE, Kazakhstan, etc. Some of our clients have become our indispensable agents and cooperate with us very well.
Certificates ensure the YONGLI reputation:
Our clients:
Our Service:
We have successfully produce over 1000 turnkey project lines to clients, which make us win one of the biggest manufacturer and the most powerful factory for biomass machine in this area. We have already sold our pellet machine turnkey projects to over 80 countries, they are: Latvia, Lithuania, Russia, Slovenia, France, Italy, Tunisia, New Zealand, Australia, Colombia, Brazil, Uruguay, Vietnam, Malaysia, Singapore, Indonesia etc, for some clients, they have become our indispensable agents and cooperate with us very well.
