CE Quality 5-400tph Grain Corn Bucket Elevator/elevator Buckets
- Shanghai Port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Type | Bucket Conveyor | |
| Material | Rubber | Material Feature | Heat Resistant | |
| Structure | Belt Conveyor | Load Capacity | depend on models | |
| Place of Origin | Jiangsu, China | Brand Name | YONGLI | |
| Model Number | SPD600 | Voltage | 380V, 400V, 415V | |
| Power(W) | 4.5-90 kw | Dimension(L*W*H) | Customized | |
| Certification | CE, ISO9001 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
CE quality 5-400tph grain corn bucket elevator/elevator buckets
Application of Bucket Elevator:
Bucket elevator is widely applied in vast industries like metallurgy, chemical industry, building materials, mine, grain and vegetable oil, food, fodder, plastic and medicine
Advantages:
Large transmission capacity
- Elevate the capacity up to 5-800 cubic meters / hour.
Low energy consumption
- This machine used for the flowing feed method, gravity induced discharging the material. And use the Intensive large capacity hopper conveyor.
Low chain speed, big transmission capacity
- No material flow back, small drive power, Theoretical calculation Shaft power is 25%-45%
Long service life
- Used the flowing feed method between the material and hit during the feed and elevating process, so this prevent abrasive cost. Strengthen wear resistant chain enlarge the service life of the chain and hopper for more than 5 years.
Higher Lifting height
- With low speed of the chain speed, stable working, and the use of strengthed wear-resistant chain ensure higher lifting height.
Good sealing, reduce environmental pollution.
We design different bucket elevator according to specific requirement.
Features of TDTG Series Bucket Elevator
- Equipped with explosion relief port, it can prevent dust explosion and ensure safety.
- Adopt anti-back device, which prevent product blockage caused by equipment stoppage.
- Adopt EP belt, low extendibility, endurable and reliable.
- Feeding could be in both shaft-end and upwards direction.
- Adjusting plate adopts sealing treatment, no leakage of product when tensioning the belt by screw device.
- Middle casing adopts specialized edge-meshing combination process, with high strength and good sealing.
- Optional with off-tracking alarm and speed monitor system.
- Compact structure, beautiful appearance, high output and high conveying capability.
- Rubber covering technology is adopted for head pulley to increase friction coefficient and prevent belt from slipping.
Technical Parameters of Bucket Elevator:
Model | TDTG36/13 | TDTG36/18 | TDTG36/23 | TDTG36/28 | TDTG50/23 | TDTG50/28 | TDTG60/30 | TDTG60/33 | TDTG80/46 | TDTG100/33*2 | TDTG100/47*2 |
Capacity | 5-8 | 10 | 15 | 20 | 25-40 | 40-60 | 60-100 | 80-130 | 100-180 | 150-200 | 300-400 |
- Each machine is well packed by thin films.
- Use iron case or iron pallet to fix the machine strongly.
- Each products are ensured to arrive on time based on sales order requirements.
-24 Hours Online Service.
-Inquiry will be replied within 2 hours.
-All-the-way tracking service offered from placing order to delivery.
-Free training for operation, debugging and daily maintenance.
-We can provide professional guide installation.
-One year warranty and all-round after-sales service.
-Customized design and flow chart are available for our clients.
-Independent R&D team and strict & scientific management system.
-15 years' experience in conveyor and other machinery production field.
-7 years Golden Supplier in Alibaba.
-21 National patents by government.
-Over 200 stuff and 22,000sm factory occupation
-Specialized in designing, researching, developing, manufacturing and exporting.
-Approved ISO9001 and international certificate: CE and SGS
-Exported to over 50 countries and finished more than 1,000 turn-key projects.
Certificates:
1.Will you help with installation and stuff training ?
Yes, we can send our engineers to your place to guide the installation and train your workers.
2.How do you control the quality?
We insist "Quality is priority” and always pay great attention to quality control from the very beginning to the end. You can also be reassured by our one-year warranty and CE&ISO9001 Certificates.
3. Where is your factory located? How can I visit there?
Our factory is located in Liyang City, Jiangsu Province, China, near Shanghai; and our
International Business Centre is in Nanjing City. You can fly to Shanghai airport or
Nanjing Airport directly. All our clients, from home or abroad, are warmly welcome to
visit us!
