Specifications
automatic tin can labeling machine1. auto cans labeling machine
2.100-450can/min capacity adjustable
3.can shrink labeling
Automatic tin can labeling machine
Features:
All-cover type stainless steel host machine: the whole machine is waterproof as well as rustproof.
Adjustable cutter head: unique cyclotron cut-off, double sided cutting edge with a long service life.
Single positioning centre guide pillar: more stable for label delivery.
Synchronous bottle divider: a more stable transmission for the bottle.
Bottom set label brush: more precision for casting label.
Label-controlling electric-eye shelf: unique combination of tail and electric-eye to improve the precision for cutting off the membrane materials.
Push-button control cabinet: a more humanized operation.
Independent feeding material shelf: the position of the material shelf is optional at will.
Electrical Appliance Configuration Specification
It adopts PLC programmable controller, imported servo motor, servo driver, frequency converter and transducer; also, it adopts the positioning module to ensure the casting label precise, rapid and stable.
Application |
labeling |
Machine size |
L2000*W850*H2000mm |
Applicable bottle |
all kinds of cans |
Brand name |
Royal |
Bottle heigth |
30-250mm |
Bottle diameter |
48-96mm |
Speed |
150BPM |
Lebel thickness |
30-250mm |
Thickness of label |
0.03-0.13MM |
Applicable label |
PVC, PET,OPS label |
Input voltage |
380/220VAC |
Input power |
2kw |
CNC or not |
YES |
Motor type |
servo system |
Control system |
micro PC |
Shrink way |
steam shrinking |
Dynamic focusing device |
YES |
Working table |
ground |
Certification |
SGS,CE,ISO,GMC |
Place of origin |
zhangjiagang city,Jiangsu Province |
Machine weight |
500kg |
