Help CenterLiquid Filling Sealing Machine
Related Products
Specifications
1. PLC control, touch screen2. torque control
3. no cap, not capping
4. no hurt caps
5. compact structure
Main characteristic:
This is our newly developed capping machine, integrates bottle inlet, cap sort, cap feed, capping, bottle outlet together. Well suitable for diversified caps, also very friendly applicable for anti-theft caps. Caps are grasped and positioned well, harmless to caps during the machine running. Fast speed of machine and high qualified rate of capping, it bears step less adjusting, can reach the international advanced level of similar products.
Electric elements use international famous brand, which ensure the machine’s quality and its service lifetime, reasonable structure, superior performance, low voice, friendly environmental.
The surface of this machine has been polished with good looking. It can be well matched with the production line. It is an ideal equipment for large and medium factories.
Working principle:
(1)This capping machine adopts rotary type for screwing caps. Caps are oriented and supplied to the cap grasping area, capping heads grasped caps send to capping area by compressed air for doing
capping work, finally capper bottles are outlet by conveyor.
(2) Caps tighten can be adjusted by clutch.
(3) Bottle inlet can cap inlet are controlled synchronously
(4) Reversed caps can be ejected. (optional function)
Technical parameter:
No. |
Item |
Performance |
|
01 |
Suitable bottles |
||
|
diameter |
Φ40mm~Φ100mm |
|
|
height |
80mm~280mm |
|
02 |
Suitable caps |
||
|
height |
10mm~35mm |
|
|
diameter |
Φ20mm~Φ80mm |
|
03 |
Power supply |
AC 380V; 50Hz |
|
04 |
Power |
3 Kw |
|
05 |
Pneumatic (air-operated)source |
0.6 Mpa clean and stable compressed air |
|
06 |
Number of capping heads |
6 heads |
|
07 |
Production capacity |
≤6000 bottles/hour |
|
08 |
Weight |
about 980 Kg |
|
09 |
Dimension (L×W×H) |
2000mm×1300mm×2400mm |
|
1.Machine warranty: One year;Spare parts free of charge are supplied within one warranty year ,easy damaged parts and man-made damaged are exclusive,over warranty year the seller only charge spare parts at cost price;
2.The seller provides the buyer long time technology supply;
3. All operation manual, operation interface offered in English. Offering free-charge machine operation training.
