Plastic Bottle Unscrambling Equipement/Unscrambler Machine for PET Bottles

Plastic Bottle Unscrambling Equipement/Unscrambler Machine for PET Bottles photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Food, Beverage, Other, Food, Beverage, shrink labels on bottle
Packaging Type:
Bottles
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Food, Beverage, Other, Food, Beverage, shrink labels on bottle
Packaging Type Bottles
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Voltage customized
Power according to requirement
Place of Origin Jiangsu, China
Brand Name HS-Packing
Model Number LP
Certification CE,ISO,UL

Specifications

automatic bottle unscrambler machine
1.PET/plastic bottle unscrambling equipement
2.beverage filling &packing equipement

Plastic Bottle Unscrambling Equipement/Unscrambler Machine for PET bottles



Working principle:
When the bottle elevator is started, the disordered bottles will be transferred on top of umbrella shape tower, and then

fall into bottle ascending-descending devices.

The bottle ascendidescending devices will push bottles into bottle dropping grooves under the action of cam.

Then the ordered bottles will be sent out through planet wheel into air conveyor. Planet wheel is connected with motor main axis by synchronous belt.
 Main Technical Technology

1

Number of working positions



16

2

Rationed capacity

10000 bottles /hour

3

Max .capacity

12000 bottles/ hour

4

Air pressure

0.7MPa

5

Air consumption

1.5M3/ min

6

Applicable bottles. diameter

50-96MM,

7

Applicable bottles. Height

165-300MM

8

Main motor

1.5KW

9

Lifting motor

0.75KW

10

Fan

2.2KW

11

Dimension

Approx Φ2200×2340mm (diameter × height

12

Weight

Approx  3600 Kg



Photos  for reference

Plastic Bottle Unscrambling Equipement/Unscrambler Machine for PET bottlesPlastic Bottle Unscrambling Equipement/Unscrambler Machine for PET bottles



Plastic Bottle Unscrambling Equipement/Unscrambler Machine for PET bottles
