PVC and Paper Laminating machine PVC and Paper Laminating machine :
It has such advantage as high efficiency and sticking paper without wrinkle or bubbles,etc.
Woodworking paper laminating machine have been improved greatly based on the TG-III paper laminating machine in furniture,with the features of more advanced technical configure,highter precision,more reasonable layout,more facilitate structure,more convenient operation(full automatic) and have reached advanced international level.
Equipment configure:dust collection and absorption equipment,
Functions:
single spread glue electromagnetism brake equipment,rotary paper cutting equipment,big diamneter roller and oil-heating pressure equipment which is excellent evenly conduct heating properly.
| Paper laminating machine for furniture TMB | |||
| Technical specification | |||
| Ø320×1350mm | Mode specification | Ø320×1350mm | |
| 600mm | Min.Board length | 600mm | |
| 1220mm | Board width | 1220mm | |
| 2-30mm | Board thickness | 2-30mm | |
| 1-25m/min | Feeding speed | 1-25m/min | |
| 9.6kw | Motivity power | 9.6kw | |
| 36kw | Heating power | 36kw | |
| 1280mm | Paper width | 1280mm | |
| 6180×1980×1780mm | Overall Dimensions | 6180×1980×1780mm | |
| 5800kg | Machine weight | 5800kg | |
