Specifications
Automatic woodworking cnc machines for sale:1) Main shaft rotation: 4,700r/min
2) Max. process thickness: 80mm
Easy operate
Automatic woodworking cnc machines for sale:
1) Main shaft rotation: 4,700r/min
2) Max. process thickness: 80mm
3) Max. process length: 2,600mm
Type: Automatic woodworking cnc machines for sale
4) Main saw shaft diameter: Φ75mm
5) Main saw blade diameter: Φ350mm
6) Semi-blade diameter: Φ22mm
7) Total power: Φ120mm
8) Feeding speed: 20kw
9) Overall size: 5200 x 4200 x 1700mm
10) Weight: 3000kg
Technical specification
Max.Cutting Length:2600mm
Max.Cutting Thickness:90mm
Diameter of Main Saw Blade:Φ400mm
DIameter of Manin Saw Spindle :Φ75mm
Rotation Speed of Main Saw Blade :4800r/pm
Diameter of Scoring Saw Blade :Φ180mm
Diameter of Scoring Saw Spindle :Φ45mm
Rotation Speed of Scoring Saw Blade :6500r/pm
Forward Speed of Saw Carriage(stepless) :10-40mm
Backward Speed of Saw Carriage : 60m/min
Drive Motor of Main Saw Blade :11kw
Drive Motor of Saw Carriage : 1.5kw
Automatic Feeding Motor :1.0kw
Total power consumption :20kw
Automatic Feeding Speed :20-50m/min
Pnenmatic Pressure :5-7kg/cm2
Table height from floor :960mm
Net Weight :5800kg
Overall Dimensions(LχWχH) :5200X6630X1820mm
