Specifications
LC Fiber Optic Patch CordLow IL and High RL
High precision alignment
Various fiber optic patch cords with good price
ROHS
LC Fiber Optic Patch Cord Characteristics:
- Compact, pull-proof design, with RJ-45 style interface
- Fully compatible with standard LC products
- Optional anti-snag simplex collar and duplex clip
- Patch Cord body can be used for both simplex and duplex configurations
- Average insertion loss: 0.06 dB
- Average return loss: 55 dB
- Plastic housing and boot made from UL-rated materials
LC Fiber Optic Patch Cord Application:
- Telecom / Datacom, LANs, CATV
- Fiber to the Home, Premises Distribution
- Gigabit Applications (Ethernet, ATM, SONET, etc.)
LC Fiber Optic Patch Cord Brief Introduction
LC Fiber Optic Patch Cord are small form factor fiber optic Patch Cord. The LC Fiber Optic Patch Cord resemble a small LC fiber Pigtails. Lucent Technologies first developed the LC Patch Cord for TelCo environment uses. Hence, LC stands for Lucent Pigtails.LC fiber Pigtails have been standardized as FOCIS 10 (Fiber Optic Patch Cord Intermateability Standards) in EIA/TIA-604-10. The LC Fiber Optic Patch Cord uses a 1.25 mm ferrule, half the dimension of the ST ferrule or a regular ceramic ferrule Patch Cord. The LC gives excellent performance and is greatly preferred for single mode transmission.
The TELEWEAVER LC Unibody is fully compatible with the original LC family of single-mode and multimode Pigtails, adapters and associated components, manufactured under a worldwide license from OFS Fitel. The Unibody features a compact, pull-proof design with RJ-45 style interface, and features a one-piece molded housing with internal strength member, for significantly improved 90º side-pull performance under Telcordia GR-326-CORE testing. It is manufactured using a ruggedized material that results in a latch trigger up to four times stronger than average.
The LC Unibody Series includes an optional anti-snag collar that prevents accidental tear and damage in high density networks. The collar comes in either simplex or duplex configurations, and can be used on the same Patch Cord body, eliminating the need to purchase different housing styles. The series includes a jumper Patch Cord designed for 2.0mm cordage, and a Behind the Wall (BTW) version for 900µm buffered fiber. The Unibody can be used for single-mode and multimode applications with either a PC or APC end-face. Plastic housing and boot made from UL rated materials are also available. The series is compliant with Telcordia GR-326-CORE, IEC 61754-20, and TIA/EIA 604-10 standards, and meets independent testing criteria from OFS Fitel.
LC Fiber Optic Patch Cord Pictures:
-
LC Fiber Optic Patch Cord
LC Fiber Optic Patch Cord Paramters:
|
Type Parameters |
Single-mode |
Multimode |
||
Patch Cord Type |
LC Fiber Optic Patch Cord |
|||
Polishing Type |
PC |
UPC |
APC |
PC |
Insertion Loss (dB) |
≤0.2 |
≤0.25 |
||
Return Loss (dB) |
≥45 |
≥50 |
≥60 |
N/A |
Repeatability (dB) |
IL≤0.2 RL≤5 |
IL≤0.1 |
||
Vibration (dB) |
IL≤0.2 dB RL≤5dB |
IL≤0.2 dB |
||
Exchangeability (dB) |
IL≤0.2 dB RL≤5dB |
IL≤0.2 dB |
||
Tensile Strength |
F200N |
|||
Durability |
n=1000 |
|||
Operation Temperature (°C) |
-40°C~+80°C |
|||
Ferrule Material |
Zirconia Ceramic |
|||
Cable Diameter (mm) |
Ø0.9, Ø2.0, Ø3.0 |
|||
