Help CenterTWSWT7024S 24 Port Fiber Switch
Related Products
Specifications
TWSWT7024S 24 port fiber switchVarious fiber ports optional
Different configurations
Wide Network Protocol / Standard
TWSWT7024S 24 port fiber switch Characteristics:
- 8K address table for auto-learned unicast addresses
- Jambo frame supports up to 2048 bytes.
- 802.1p and Port based QoS package classification with 4 priority queues.
- 4K 802.1Q based VLAN
- Port based VLAN.
- 16 Protocol based VLAN.
- 13 trunk groups of up to 8 member ports for flexible load distribution control and fail-over function.
- 802.1d Spanning Tree Protocol, 802.1w Rapid Spanning Tree Protocol
- By-port egress, ingress, bi-direction rate control
- Storm Control
- 802.3x flow control for a full-duplex mode and collision-based backpressure for a half-duplex mode
- User configurable port mirroring supports ingress/egress/both data flow monitoring on one or more ports.
- User account assignable to one of the two access privilege levels
- On-line firmware upgrade
- Dual power supply modules provide power redundancy with status monitoring features.
- Network Management
- Web page management
- Port Configuration
- Twenty-four 100Base-FX SC/PC ports
- Fiber Optic Interface Options
- 100Base-FX
- Single single-mode fiber, dual wavelength 1550nm/1310nm, SC/PC connector, operating distance 15/40km.
- Dual single-mode fiber, single wavelength 1310nm or 1550nm, dual SC connectors, operating distance 15/40/60km.
- Dual multimode fiber, single wavelength 1310nm, dual SC connectors, operating distance 2km.
- Power Supply Options
- AC90~264V/1.2A max, 50/60Hz
- DC36~72V/1.5A.
- Power Consumption: no more than 45W
- Dual power supply optional
- Physical and Environmental
- Dimensions: 19-inch rack-mount width, 1.0U height.
- Weight: 5Kg
- Operating temperature:0°C~50°C
- Storage temperature:-25°C~85°C
- Humidity: 5% ~ 95% RH Non-condensing.
TWSWT7024S 24 port fiber switch Brief Introduction
TWSWT7024S-FX Smart Fiber Optic Ethernet Switch is a high-performance smart Layer 2 switch for optical LAN, which offers up to twenty-four 100Mbps Fast Ethernet fiber optic ports.
TWSWT7024S-FX is designed to meet the emerging fiber optic Ethernet requirement, and its completed and rich feature set provides flexibility of meeting different applications; especially in optical LAN (such as FTTD), Ethernet based DCS and security surveillance system. The optional dual power supplies design provides the redundancy for high reliability applications. The low profile appearance with standard rack-mount size achieves 24 fiber ports within a single rack, providing users the best performance/price ratio.
TWSWT7024S-FX network management solution allows administrators to easily configure features, monitor performance, and troubleshoot the switches using Web-based network management platforms.
Main applications: Fiber optic LAN, industrial Ethernet, Ethernet based DCS and digital video surveillance system.
TWSWT7024S 24 port fiber switch Pictures:
-
TWSWT7024S 24 port fiber switch
