TWSWT7424S gigabit fiber switch

TWSWT7424S gigabit fiber switch Characteristics:

1. 8K address table for auto-learned unicast addresses
2. Jambo frame supports up to 2048 bytes.
3. 802.1p and Port based QoS package classification with 4 priority queues.
4. 4K 802.1Q based VLAN
5. Port based VLAN.
6. 16 Protocol based VLAN.
7. 13 trunk groups of up to 8 member ports for flexible load distribution control and fail-over function.
8. 802.1d Spanning Tree Protocol, 802.1w Rapid Spanning Tree Protocol
9. By-port egress, ingress, bi-direction rate control
10. Storm Control
11. 802.3x flow control for a full-duplex mode and collision-based backpressure for a half-duplex mode
12. User configurable port mirroring supports ingress/egress/both data flow monitoring on one or more ports.
13. User account assignable to one of the two access privilege levels
14. On-line firmware upgrade
15. Dual power supply modules provide power redundancy with status monitoring features.
16. Network Management
17. Web page management
18. Port Configuration
19. Gigabit ports: two optional standard SFP based 1000Base-X ports and two 10/100/1000BaseTX RJ45 ports
20. Twenty-four 100Base-FX SC/PC ports
21. Fiber Optic Interface Options
22. SFP 1000Base-X
23. Dual multimode fiber(50/125μm), single wavelength 850nm, dual LC connectors, operating distance 550m.
24. Dual multimode fiber(62.5/125μm), single wavelength 850nm, dual LC connectors, operating distance 275m.
25. Dual single-mode fiber, single wavelength 1310nm or 1550nm, dual LC connectors, operating istance 15/40km.
26. 100Base-FX
27. Single single-mode fiber, dual wavelength 1550nm/1310nm, SC/PC connector, operating distance 15/40km.
28. Dual single-mode fiber, single wavelength 1310nm or 1550nm, dual SC connectors, operating distance 15/40/60km.
29. Dual multimode fiber, single wavelength 1310nm, dual SC connectors, operating distance 2km.
30. Power Supply Options
31. AC90~264V/1.2A max, 50/60Hz
32. DC36~72V/1.5A.
33. Power Consumption: no more than 45W
34. Dual power supply optional
35. Physical and Environmental
36. Dimensions: 19-inch rack-mount width, 1.0U height.
37. Weight: 5Kg
38. Operating temperature:0°C~50°C
39. Storage temperature:-25°C~85°C
40. Humidity: 5% ~ 95% RH Non-condensing.
41. Ordering Information
42. SFP 1000Base-X module
43. SFP1000SX: Dual multimode fiber SFP module, operating distance 275/550m.
44. SFP1000LX-15: Dual single-mode fiber SFP module, operating distance 15km
45. SFP1000LX-40: Dual single-mode fiber SFP module, operating distance 40km

TWSWT7424S gigabit fiber switch Brief Introduction

TWSWT7424S-FX Smart Fiber Optic Ethernet Switch is a high-performance smart Layer 2 switch for optical LAN, which offers up to twenty-four 100Mbps Fast Ethernet fiber optic ports, as well as two Gigabit Ethernet fiber optic ports and two 10/100/1000M RJ45 copper ports.

TWSWT7424S-FX is designed to meet the emerging fiber optic Ethernet requirement, and its completed and rich feature set provides flexibility of meeting different applications; especially in optical LAN (such as FTTD), Ethernet based DCS and security surveillance system. The optional dual power supplies design provides the redundancy for high reliability applications. The low profile appearance with standard rack-mount size achieves the highest fiber port density within a single rack, providing users the best performance/price ratio.

TWSWT7424S-FX network management solution allows administrators to easily configure features, monitor performance, and troubleshoot the switches using Web-based network management platforms.

Main applications: Fiber optic LAN, industrial Ethernet, Ethernet based DCS and digital video surveillance system.

TWSWT7424S gigabit fiber switch Pictures:

1.


   TWSWT7424S gigabit fiber switch
