Help CenterST Fiber Optic Pigtail
Related Products
Specifications
ST Fiber Optic PigtailLow IL and High RL
High precision alignment
Various fiber optic pigtails with good price
ROHS
ST Fiber Optic Pigtail Characteristics:
- Bayonet style housing for easy termination
- Epoxy and epoxy-less versions
- High precision alignment
- Low insertion and return loss and back reflection
ST Fiber Optic Pigtail Application:
- Optical Fiber Communications, Video, LAN, CATV Systems
- Optical Network Equipments, Optical Test Equipments
- Optical Network Equipments,optical Test Equipments
- Module Pigtails, Multi-media, Premise
- Active device termination installations
ST Fiber Optic Pigtail Brief Introduction
ST fiber Pigtail is still the most popular Pigtail, this fiber Pigtail has a bayonet mount and a long cylindrical 2.5 mm ceramic (usually) or polymer ferrule to hold the fiber. Clearly speaking, The ST fiber Pigtail (Straight Tip) is a fiber Pigtail which uses a plug and socket which is locked in place with a half-twist bayonet lock. The ST Pigtail was the first defactor standard for fiber optic cabling and ST fiber Pigtail is one of the leading fiber Pigtails.
The TELEWEAVER ST Pigtail has a bayonet-style housing and a long spring-loaded ferrule hold the fiber. They are available in both multimode or singlemode versions. Horizontally mounted simplex and duplex adapters are available with metal or plastic housing, with a choice of phosphor bronze or zirconia split sleeve. TELEWEAVER also offers the epoxy-free ST XPFit Pigtail for quick field termination. The ST is one of the older generations of Pigtail, but is still widely used for multimode networks, including LANs for buildings and campuses.
ST Fiber Optic Pigtail Pictures:
-
ST Fiber Optic Pigtail
ST Fiber Optic Pigtail Paramters:
|
Type Parameters |
Single-mode |
Multimode |
||
Pigtail Type |
ST Fiber Optic Pigtail |
|||
Polishing Type |
PC |
UPC |
APC |
PC |
Insertion Loss (dB) |
≤0.2 |
≤0.25 |
||
Return Loss (dB) |
≥45 |
≥50 |
≥60 |
N/A |
Repeatability (dB) |
IL≤0.2 RL≤5 |
IL≤0.1 |
||
Vibration (dB) |
IL≤0.2 dB RL≤5dB |
IL≤0.2 dB |
||
Exchangeability (dB) |
IL≤0.2 dB RL≤5dB |
IL≤0.2 dB |
||
Tensile Strength |
F200N |
|||
Durability |
n=1000 |
|||
Operation Temperature (°C) |
-40°C~+80°C |
|||
Ferrule Material |
Zirconia Ceramic |
|||
Cable Diameter (mm) |
Ø0.9, Ø2.0, Ø3.0 |
|||
