Home > Products > Ex junction box > Professional corrosion proof flameproof connecting Box
Professional corrosion proof flameproof connecting Box
- 10000 Piece / Pieces per Month
- NINGBO/SHANGHAI
- T/T D/P D/A
- 30A automatic transfer switch
- Hot selling rack cabinet weatherproof/SK-235M waterproof telecom outdoor cabinets with fan
- Hot selling rack cabinet weatherproof/SK-291 outdoor telecom cabinet rack
- Hot selling rack cabinet weatherproof/SK-345 outdoor waterproof cabinet
- Hot selling rack cabinet weatherproof/ SK-400B fan type ip54 battery cabinet
- Hot selling rack cabinet weatherproof/SK-235M waterproof outdoor racks with fan
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | FPFB | Model Number: | BJX8050- |
Protection Level: | IP65 | Type: | Junction Box | External Size: | 360*360*120 |
Product Description
Professional corrosion proof flameproof connecting Box
1. Can be used in hazardous areas: Zone 1 and Zone 2 .
2. Can be used in explosive gas atmospheres of Category IIA, II B and II C where the temperature classification is T1-T6.
3. Hazardous zone : 20. 21. and 22
4. Flammable dust atmosphere.
5. widely using in the fields of oil, chemical industry , spaceflight ,war industry and so on.
Rated Voltage | Dust-mark | Inlet thread | enclosure material | Ex-mark | Degree of protection | Erosionproofclass | cableouterline (mm) |
AC220/380v | DIP A21 TA,T6 | G1"~G2" | GRP | Exed II T6 Gb | IP65 | WF2 | Φ6mm~Φ38mm |
APPlications:
- Suitable for explosive gas environment Zone1 and Zone2.
- Suitable for IIA,IIB,IIC explosive gas environment.
- Suitable for Hazarous dust area: Zone20, Zone21, Zone22.
- Can be used in the environment of temperature group for T1~T6.
- Designed for petroleum explosion, refinery, storage, chemistry, medicine, military etc. sites with potential explosive atmosphere.
- Can be used as division and connection of cables.
Techinical parameters:
- Meet a criterion:G3B3836.1, GB3836.3, GB12476.1,IEC60079-0, IEC60079-7, IEC61241-1, EN60079-0, EN60079-7, EN61241-1
- Ex-proof Mark:Exe II T6 Gb, DIP A21 TA, T6.
- Rated voltage: AC220/380V
- Protection grade: IP65
- Corrosion-proof grade:WF2
- Inlet Thread: G1"~G2"
- Rated current: ≤100A
- Cable outer dia: Φ6mm~Φ38mm.
Product Features:
- Glas reinforced polyester enclosure, with the elegant shape, corrosion resistance, static, electricity, resistance, impact resistance and good thermal reliability.
- Labyrinthsealing structure, design and with the functions of waterproof and dustproof.
- Exposed fasteners of stainless steel and uses anti-lost type design, which to be convenient for user to install and maintain.
- Terminal can selected for line pressed type or pheonix's special terminal of safety-increased type.
- Built-in terminal number, inlet's direction, inlet's number and specification are determined by use.
- Can be use to sub-connect or connect the electrical control circuits, and also applicable to connect supply wire of self- control engineering or communication's signals.
- Steel pipe and cable wiring.
Feipu Explosion-proof Electric Co., Ltd. is an advanced electrical solution provider for hazardous areas of zone1, zone 2, and zone 20, zone 21, zone 22.
We have wide range explosion proof products of lamp & light fixtures, electrical equipments, and box & fittings. And excellent company crew of R&D, marketing and artificers that has abundant experience in both Chinese domestic market and overseas markets.
Our products and projects occur in various occasions of petroleum, chemical, military and workshop across the world.
We care the most of quality and stability of our products, as well as efficient communication and positive service to our customers and partners.
Dear Customers,
Welcome to visit FPFB online marketing display.
To serve you in a better and efficient way, please browse our products and contact us with following information.
1. Where is the occasion products will be used, petroleum refinery, chemical factory or industrial workshop?
2. What is the purpose from products? Routine illumination, field illumination, platform lighting, emergency or portable.
3. Your preference on light source, power and installation methods etc.
We will offer our best products and prices according to your actual demand.
Sincerely yours,
FPFB sales team.
1. What is our advantage in the industry?
Our main advantage is high performance price ratio of our products, and positive service to our customers and partners.
Our products are not the top grade of quality in the industry, and our prices are not the lowest as well, but the performance price ratio of our products is outstanding.
2. What is our sales and distribution policy?
We welcome all kinds of business cooperation methods, including region distributors, new market agencies, project & bid buyers, and end user procurement.
3. Do you have warranty policy?
We offer at least 2 year-warranty for our products, longer warranty for certian products, and full lifespan aftersales service.
1. Standard export packing or customized packing available.
2. Shipping arrangement according to buyers request.
