250W 400W explosion proof floodlight street light fixtures BAT53
Youtube video web: /watch?v=tMZw5qKZZJg
1. Can be used in hazardous areas: Zone 1 and Zone 2 .
2. Can be used in explosive gas atmospheres of Category II B and II C where the temperature classification is T1-T4.
3. Hazardous zone : 20. 21. and 22
4. Flammable dust atmosphere.
5. widely using in the fields of oil, chemical industry , spaceflight ,war industry and so on.
Voltage |
RATED power |
INLET thread |
Lighting source |
Ex-mark |
Degree of protection |
Erosionproofclass |
cableouterline (mm) |
AC220v |
55W-400W |
G3/4" |
N,L,G,Z,J |
Exde II BT6/CT6 GB |
IP54,IP65 |
WF1
|
Φ 9- Φ 14 |
APPlications:
- Suitable for explosive gas environment Zone1 and Zone2.
- Suitable for IIA,IIB,IIC explosive gas environment.
- Suitable for Hazarous dust area: Zone20, Zone21, Zone22.
- Can be used in the environment of temperature group for T1~T3.
- 3 different Types are available.
- Designed for petroleum explosion, refinery, storage, chemistry, medicine, military etc. sites with potential explosive atmosphere.
Techinical parameters:
- Meet a criterion:G3B3836.1, GB3836.2, GB3836.3, GB12476.1,IEC60079-0, IEC60079-1, IEC60079-7, IEC61241-1, EN60079-0, EN60079-1, EN60079-7, EN61241-1
- Ex-proof Mark:Exd II BT3 Gb, Exd II CT3 Gb, DIP A21 TA, T3.
- Rated voltage: AC220V
- Protection grade: IP54,IP65
- Corrosion-proof grade:WF1
- Inlet Thread: G3/4"
- Cable outer dia:9mm~14mm
Product Features:
- Aluminium alloy Enclosure,high-pressure electrostatic powder coated after shot plastic.
- Fins type enclosure structure is convenient for heat dissipation.
- Plate toughened glass cover with good impact resistance capacity.
- Lamp compartment with thread cover convenient for maintenance and change lamp.
- O shape sealing ring at flameproof joint with good water-proof capacity.
- Guards are treated by dip craft after galvanized with aesthetic appearance and strong corrosion resistance.
- Stainless steel Exposed fasteners with strong corrosion resistance capacity.
- Ajustable 360 horizontally and 45~135 elevation.
- Steel conduit wiring.
Profile Display
Packaging Display
