KUBOTA tractor price list model B2420

FOB Price

Negotiable / Set

4 Sets(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Wheel Tractor
By wheel	4WD	Usage	Farm Tractor
Drive Type	Gear Drive	Brand Name	KUBOTA
Model Number	B2420	Place of Origin	Japan
After-sales Service Provided	No overseas service provided

Specifications

Model				B2420
				4WD
Engine	Type			Kubota D1105-E2-D22T, liquid cooled, 3-cylinder diesel
	No. of cylinders			3
	Total displacement ( cc )			1,123
	Engine gross power ( HP )			24.0@2600 rpm
	Engine net power ( HP )			21.1@2600 rpm
	PTO power ( HP )			17.4@2600 rpm
	Fuel tank capacity ( l)			26
Dimensions	Overall length (without 3P) ( mm(inch) )			2,410(94.88inch)
	Overall width ( mm(inch) )			1,015(39.96inch)
	Overall height (Top of steering wheel) ( mm(inch) )			1,350(50.39nch)
	Wheelbase ( mm(inch) )			1,563(61.54inch)
	Min. ground clearance ( mm(inch) )			325(12.80inch)
	Tread	Front ( mm(inch) )		810(32.09inch)
		Rear ( mm(inch) )		810(31.89inch), 900(35.43inch)
Weight ( kg )				595
Clutch				Dry type Single stage
Traveling System		Tires	Front	7 – 12
			Rear	8.3 – 20
		Steering		Integral type power steering
		Transmission		Gear shift, 9 forward and 3 reverse
		Brake		Wet disk type
		Min. turning radius (with brake) ( m )		2.1
		Traveling speed ( km/h )		Max. 18.8
Hydraulic		Hydraulic control system		Quarter inching valve
		Pump capacity ( l/min )		26.4 (16.6+9.8)
		Three point hitch		Category I
		Max. lift force	At lift points ( kg )	615
			24 in. behind ( kg )	480
PTO		PTO (Engine speed) ( rpm )		540 (2,600), 960 (2,552)

KUBOTA TRACTOR B2420 WITH FRAME PROTECTION

Packaging & Shipping

LCL SHIPPING

Carefully cover with plastic on the pallet

FCL SHIPPING

Loading complete tractor in the container as below

20FT: 4 sets

40FT: 10 sets
