CJX1 Series for Aissmy ac Contactor Type Magnetic AC Contactor 380-660V 110A
CJX1 series for Aissmy ac contactor type magnetic AC contactor 380-660V 110A
Function of CJX1 Series AC Mini Contactor
1.remote make & break of circuits
2.start,stop and reversing-rotation of AC motors
Features of CJX1 Series AC Mini Contactor
1.CJX1 Series AC Mini Contactor used for making/breaking electric circuit at a long distance and for frequent starting/stopping.
2.CJX1 Series AC Mini Contactor with thermal relay to compose a magnetic motor starter to protection overloaded circuits.
3.High energy-efficient of CJX1 Series AC Mini Contactor.
4.CJX1 Series AC Mini Contactor No Electric Noise .
5.Long service life and high reliability of CJX1 Series AC Mini Contactor.
6. CJX1 Series AC Mini Contactor can preventing electromagnetic interference.
| Type | CJX1-9 | CJX1-16 | CJX1-32 | CJX1-45 | CJX1-75 | CJX1-170 | CJX1-250 | CJX1-400 | ||
| CJX1-12 | CJX1-22 | CJX1-63 | CJX1-85 | CJX1-205 | CJX1-300 | CJX1-475 | ||||
| Mechanical endurance(×106) | 10 | 10 | 10 | 8 | 8 | 8 | 8 | 8 | ||
| Conventional thermal current(A) | 20 | 30 | 45 | 80 | 100 | 210 | 300 | 400/550 | ||
| Rated insulation voltage(V) | 660 | 660 | 660 | 1000 | 1000 | 1000 | 1000 | 1000 | ||
| Rated(380V)operating current(A) | AC-3 | 9/12 | 16/22 | 32 | 45/63 | 75/85 | 170/205 | 250/300 | ||
| AC-4 | 3.3/4.3 | 7.7/8.5 | 15.6 | 24/28 | 34/42 | 75/96 | 110/125 | |||
| Power of controllable motor(KW)AC-3 | 380V | 4/5.5 | 7.5/11 | 15 | 22/30 | 37/45 | 90/110 | 132/160 | ||
| 660V | 5.5/7.5 | 11 | 23 | 39/55 | 67 | 156 | 235 | |||
| Power of Controllable motor(KW)AC-4 | 380V | 1.4/1.9 | 3.5/4 | 7.5 | 12/14 | 17/21 | 38/50 | 58/66 | ||
| 660V | 2.4/3.3 | 6/6.6 | 13 | 20.8/24 | 29.5/36 | 66/86 | 100/114 | |||
| Frequency of operation(l/h) | AC3 | 1000 | 750 | 750 | 1200/1000 | 1000/850 | 700/500 | 700/500 | ||
| AC4 | 250 | 250 | 250 | 400/300 | 300/250 | 200/130 | 200/130 | |||
| Operating voltage range of coil | (0.8~1.1)Ue | |||||||||
| Power consumption of coil | Atracting(VA) | 10 | 10 | 12.1 | 17 | 32 | 58 | 84 | ||
| Starting(VA) | 68 | 69 | 101 | 183 | 330 | 910 | 1430 | |||
| Rated insulation voltage of auxiliary contacts(V) | 690 | 690 | 690 | 690 | 690 | 690 | 690 | 690 | ||
| Rated operating currentof auxiliary contacts(A) | AC15380/220 | 6/10 | 6/10 | 4/6 | 4/6 | 4/6 | 4/6 | 4/6 | ||
| DC13220V | 0.45 | 0.45 | 0.48 | 0.48 | 0.48 | 0.48 | 0.48 | |||
| Rated voltage of the control coil(V) | 50Hz | 24,36,48,110,127,220,380,etc | ||||||||
| 60Hz | 24,110,220,440,etc. | |||||||||
Package : polybag and carton box export standard package or designed by yourself .
Delivery date :within 3 weeks after get payment.
Delivery mode: Ocean shipping, Air transport, Express delivery/( Choose by the customer).
Payment terms: T/T in advance L/C at sight.
Any questions and requirements you can contact us at any time.
Contact:Linda chen
QQ: 1983214963
