22-14 AWG Clear/White Closed End Connector
Polyamide 66, UL 94V-2 flame-retardant shell.
1. Two types of sleeve to choose from aluminum or copper.
2. Resistant to vibration.
3. Provide convenient, safe and fast installation.
4. Rated to 600V max. for building wiring and 1000V max. lighting fixtures and signs.
5. We are the factory deal in wire connectors years and sell terminals to lots of domestic trading companies. So our price is very competitive. The only thing you need to do is send us the enquiry to start business.
For use in electrical appliances, lighting and household wiring.
22-14 AWG Clear/White Closed End Connector. These high quality closed end connectors provide a quick and easy connection of wires. Closed end connectors can also be called crimp caps, pigtail connectors or crimp connectors. Easy to use, just peel off wires, insert them into a connector tube and press with crimping tool.
Technical Parameters:
| Model No. | Color | Electrical Ratings | Wire Range | Packing |
|---|---|---|---|---|
| CE1 Copper | Nature |
300 V Max. 105°C (221°F) |
22-18 AWG, Cu Max. 2 #20 w/1 #18 Min. 2 #22 |
1,000 Pcs/Bag 30,000 Pcs/Ctn |
| CE1X AL | Nature |
300 V Max. 105°C (221°F) |
22-18 AWG, Cu Max. 2 #20 w/1 #18 Min. 2 #22 |
1,000 Pcs/Bag 30,000 Pcs/Ctn |
| CE2 Copper | Nature |
300 V Max. 105°C (221°F) |
22-14 AWG, Cu Max. 1 #18 w/1 #14 Min. 2 #22 |
1,000 Pcs/Bag 20,000 Pcs/Ctn |
| CE2X AL | Nature |
300 V Max. 105°C (221°F) |
22-14 AWG, Cu Max. 1 #18 w/1 #14 Min. 2 #22 |
1,000 Pcs/Bag 20,000 Pcs/Ctn |
| CE5 Copper | Nature |
300 V Max. 105°C (221°F) |
22-10 AWG, Cu Max. 3 #14 Min. 2 #22 w/2 #18 |
1,000 Pcs/Bag 10,000 Pcs/Ctn |
| CE5X AL | Nature |
300 V Max. 105°C (221°F) |
20-12 AWG, Cu Max. 3 #14 Min. 2 #18 |
1,000 Pcs/Bag 10,000 Pcs/Ctn |
| CE8 Copper | Nature |
300 V Max. for UL 600 V Max. for CSA & CQC 105°C (221°F) |
16-10 AWG, Cu Max. 2 #16 w/1 #10 Min. 2 #16 w/1 #12 |
500 Pcs/Bag 6,000 Pcs/Ctn |
Please contact with us without any hesitation! Your enquiry is warmly welcomed!
