Solar Connector MC4 male and female connector
Solar Connector MC4 male and female connector discription:
Mating safety provided by keyed housings.
High current carrying capacity.
Accommodates PV cable with different insulation diameters.
Simple on-site processing.
Multiple plugging and unplugging cycles .
Solar Connector MC4 male and female connector Technical parameters:
| Model No. | Part P/N | Cable sepcial | ||
| Connector | Terminal | Conductor size (mm²) | Cable OD (ΦDmm) | |
| MC4-CMMM-14 | MC4-CMMM-H | MC4-CM-T14 | AWG 14 (2.5 mm²) | Φ4.5- Φ8.5 |
| MC4-CMMM-12 | MC4-CM-T12 | AWG 12 (4.0 mm²) | ||
| MC4-CMMM-10 | MC4-CM-T10 | AWG 10 (6.0 mm²) | ||
| Model No. | Part P/N | Cable special | ||
| Connector | Terminal | Conductor size (mm²) | Cable OD(mm) | |
| MC4-CFPM-14 | MC4-CFPM-H | MC4-CF-T14 | AWG 14 (2.5 mm²) | Φ4.5- Φ8.5 |
| MC4-CFPM-12 | MC4-CF-T12 | AWG 12 (4.0 mm²) | ||
| MC4-CFPM-10 | MC4-CF-T10 | AWG 10 (6.0 mm²) | ||
| Rated current | 30A(2.5-6mm²) | |||
| Rated voltage | 1000V DC | |||
| Test voltage | 6000V(50Hz,1min) | |||
| Overvoltage type/pollution degree | CAT III/2 | |||
| Contact resistance of plug connector | Im Ω | |||
| Contact material | Copper, Tin-plated | |||
| Insulation material | PPO | |||
| Degree of protection | IP2X/IP67 | |||
| Flame class | UL94-VO | |||
| Safety class | II | |||
| Suitable cable | OD 4.5-8.5 (2.5-6.0mm²) | |||
| Insertion force/withdrawal force | ≤50N/≥50N | |||
| Connecting system | Crimp connection | |||
| Temperature range | -40℃~+125℃ | |||
