3P 4P IEC60947 Electrical AC DC Circuit Breaker

Shanxi Aisiman Electric Tech Co., Ltd.
3P 4P IEC60947 Electrical AC DC Circuit Breaker thumbnail-1
3P 4P IEC60947 Electrical AC DC Circuit Breaker thumbnail-2
3P 4P IEC60947 Electrical AC DC Circuit Breaker thumbnail-3
3P 4P IEC60947 Electrical AC DC Circuit Breaker thumbnail-4
3P 4P IEC60947 Electrical AC DC Circuit Breaker thumbnail-5
3P 4P IEC60947 Electrical AC DC Circuit Breaker thumbnail-6
3P 4P IEC60947 Electrical AC DC Circuit Breaker photo-1
3P 4P IEC60947 Electrical AC DC Circuit Breaker photo-2
3P 4P IEC60947 Electrical AC DC Circuit Breaker photo-3
3P 4P IEC60947 Electrical AC DC Circuit Breaker photo-4
3P 4P IEC60947 Electrical AC DC Circuit Breaker photo-5
3P 4P IEC60947 Electrical AC DC Circuit Breaker photo-6
US$ 10 - 100 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Aissmy/OEM
Model Number:
AMV(CVS)
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Aissmy/OEM
Model Number AMV(CVS)
Type Moulded Case
Poles Number Other, 3/4

3P 4P IEC60947 Electrical AC DC Circuit Breaker

Product Description

AMV(CVS) MCCB reflects the latest current limiting principle and manufacturing technology, characterized by compact structure, full modularization, high breaking, and zero arcover. Its rated insulation voltage is 690V, rated operating voltage is AC50/60Hz, 440V and below, rated current up to 630A. It's used for generating infrequent conversion and infrequent startup of the motor. Circuit breaker is equipped with overload, short circuit and under voltage protection devices, so as to protect the circuit and E type compact power equipments from damage.



3P 4P IEC60947 Electrical AC DC Circuit Breaker

Technical parameters:



Item No. AMV100EAMV100/160/250AMV400/630
Number of poles: 3P3P4P3P4P
ControlManualwith toggle with direct or extended rotary handle
ConnectionsFixedfront connections
Plug-infront conections/rear connections
Electrical characteristics as per IEC60947-2 and EN60947-2
Rated current(A)In100A100A,160A,250A400A,630A
Rated operating voltage(V)UeAC50/60Hz, 440V
Rated insulation voltage(V) Ui690V
Rated impulse withstand voltage(kV)Uimp6kV8kV
Utilization category A
Operation performanceMechanical1000085006000
Electrical200015001000
Indication and control auxiliaries
Auxiliary switch *
MX shunt coil *
MN under voltage coil *
Dimensions(mm) W X H X D 75 X 130 X 60105 X 161 X 86140 X 161 X 86140 X 255 X 110185 X 255 X 110

 3P 4P IEC60947 Electrical AC DC Circuit Breaker3P 4P IEC60947 Electrical AC DC Circuit Breaker3P 4P IEC60947 Electrical AC DC Circuit Breaker3P 4P IEC60947 Electrical AC DC Circuit Breaker
